Ningbo Best Group Co., Ltd. >> PCB Screw Terminal Fb218-3 Barrier Terminal Block

PCB Screw Terminal Fb218-3 Barrier Terminal Block

PCB Screw Terminal Fb218-3 Barrier Terminal Block
Price: US $ 0.02-0.3/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 2000/Piece
Pay Type: L/C,T/T,D/P
Prod Model: FB218-3
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Temp.Range: -40c~+105c
Application: Battery
Environmental Protection: General
Connection Mode: Push-Pull Connection
Shape: Rectangle
Contact Termination Form: Welding Connection
Brand: Fbele

Product Description



Material
screws:m2 steel zinc plated
wire guard:phosphor bronze,ni plated
pin header:brass,tin plated
housing:PA66,UL94V-0

Electrical
rated voltage300V
rated current10A
contact resistance20mΩ
insulation resistance5000MΩ/1000V
withstanding voltageAC2000V/1Min
wire range24-18AWG 1.0mm2
Mechanical
temp.range:-40c~+105c
max soldering:+250c for 5 sec
torque:0.2nm(1.7lb.in)
strip length:4.5-5mm
