| Prod Model: |
8va 10va 12va 13va 15va 20va 21va 22va 23va 25va |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Toroidal Transformer |
| Input: |
220-240VAC |
| Output: |
220-240VAC |
| Power: |
200va |
| Frequency: |
50Hz/60Hz |
| Model Number: |
200va |
| Coil Number: |
High Flux Density Grain- Oriented Silicon Steel |
| 95% Efficiency: |
Power Factor: 0.9 to 0.98 |
| Transformer: |
Audio Ring Transformer |
| Application: |
Audio |
| Phase: |
Single |
| Coil: |
Core-type Transformer |
| Cooling Method: |
Dry-type Transformer |
| Winding Type: |
Auto-transformer |
| Usage: |
Power, Electronic, Audio, Instrument, Rectifier |
| Brand: |
Grewin Toroidal Transformer |
Product Description
Minature Transformers:
1.The dimension of the Control Transformer Usage &Toroidal Coil Structure step-up auto-transformator 380V to 200V
The Partial List of GW-B Series Toroidal Transformers with Cable and Mounting Holes:
A
1. Installation:
Horizontal (non-conventional-type base plate), sunk, side type, and bridge.
2.Application:
Especially low-hum and low-dispersing construction
Low-level of induction
High-grade design casing possible
Statically shield winding and magnetical shield winding optional .
Be used widely such as audio equipment,communication,new energy areas,Electrical control,Cable TV network etc.
3.Equipment:
Over 50 sets toroidal/annular/ ring coil winding machines, 3 EI type transformer lines, 2 sets of vacuum annealing furnaces, A set of nitrogen and hydrogen production equipment as below:
. Automatic Winding Machine
. Semi-automatic Winding Machine
. Toroidal Winding Machine
. Insert Lamination Machine
. Wave Soldering Machine
. Plastic Termal Ultraviolet Machine
. Domino Ink Jet Printing Machine
Transformer Multitester for High & Low Frequency
Layer Insulation Withstand Voltage Tester
4.Warning
Under no circumstances should both ends of the fixing bolt simultaneously contact the metal chassis or framework as this would create a potentially dangerous 'shorted-turn'.
5.Certificate
The certificate of our transformer has CE CQC RoHs UL
6.Note
The above-mentioned toroidal transformer is frequently-used, we can also manufacture the products by customer design. And the specification is for reference, if has the change further, please take the material object as the standard.
7.GREWIN'S Dimension :
External diameter: 55mm-300mm, height :13mm-130mm, Efficiency: 75-98%
we can design the appropriate products according to customers' requirments such as installation dimension, input and output voltage,power...etc.)About us:
