| Prod Model: |
PE separator |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Thickness: |
16, 18, 20, 25, 30 Micron, etc |
| Width: |
Customerization |
| Technology: |
From Japan, Made in China |
| MOQ: |
50sqm |
| Tensile Strength: |
More Than 90 MPa |
| Product Name: |
PE Ion Exchange Memberane separator for Lithium Ba |
| Application: |
High-voltage |
| Type: |
A Type Insulator |
| Material: |
Polyethylene |
| Structure: |
Ion Exchange Separator |
| Usage: |
Battery Application |
| Connection Method: |
No |
| Size Of Bearing Capacity: |
No |
| Brand: |
Gelon |
Product Description
Welcom to contact us any time:
Mobile:+86 13255390189
PE Ion Exchange Memberane Seperator for Lithium Battery Materials Product properties of Li-ion Battery separators/membranes/PE film:
1.Thickness:16&18&20&25&30&40micron
2.Width:your request
3.MOQ:50Sqm
Breif introduction of Li-ion Battery separators/membranes/PE film:
Lithium-ion battery separator is a knid of microporous membrane, colors ranges white to beige. It is made of polyolefin resin with wet drawing process.The product has good mecanical property and chemical stability.
Applications of Li-ion Battery separators/membranes/PE film
It is used between positive and negative electrode of lithium ion batteries to prevent short cuicurt.
18micron thickness PE film separators membranes specification:
Term | Unit | Inspection value |
Appearance | | Ivory-white |
Thickness | micron | 18±2 |
Gas permeability | Sec/100ml | 350-500 |
Porosity | % | 38-44 |
Puncturing Strength | g | >300 |
Tensile strength MD | Mpa | >90 |
Tensile strength TD | Mpa | >100 |
Film close temperature | °C | ≤135 |
Film break temperature | °C | ≥147 |
90°C heat shrink MD | % | ≤3.5 |
90°C heat shrink TD | % | ≤2 |
105°C heat shrink MD | | ≤5 |
105°C heat shrink TD | | ≤3 |
120°C heat shrink MD | % | ≤20 |
120°C heat shrink TD | % | ≤1 |
Pictures
We could supply one stop solution ( turn key project) for lithium ion battery production line.
1.Full set of lithium battery materials,including :
LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Aluminum foil,copper foils,battery separator,etc.
2.Full set of lithium battery equipments,for example:
mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.
3.Full set of lithium battery technology.
we can design the laboratory and production line,according to customer's request.
Tks for your time,welcome to inquiry.
Gelon (Int) LIB Group Ltd. was set up as a manufacturer and exporter in 2007, dealing with lithium battery materials, equipments, technology, etc. Now we have Gelon New Battery Materials Co., Ltd., E-Battery Lithium Battery Co., Ltd., Linyi Dake Trading Co., Ltd., with total manufacturing facilities of around 100, 000 square meters and more than 500 staff. Owning a group of experienced engineers and staff, we can bring you not only reliable products and technology, but also excellent services and real value you will expect and enjoy.
Gelon New Battery Materials Co., Ltd. Focus on R&D, manufacturing and sales of new materials (anode, cathode, separator, additive etc. ) for lithium ion battery, and we also offer full sets of materials solution to customers. Our preponderant products are Lithium Iron Phosphate(LiFePO4), Lithium Manganese Dioxide(LiMn2O4), Lithium Cobalt Oxide(LiCoO2), Lithium Nickel Manganese Cobalt Oxide(LiNiMnCoO2), Lithium Titanate Oxide(LTO) materials; Graphite materials (MCMB) and separator and so on for new power lithium ion batteries.
Meanwhile, we have our own lithium ion battery factory- E-Battery Co., Ltd., mainly produces lithium ion battery for camera, mobile, EV application. Based on the factory, we can offer all services (Raw Materials, Equipments, Technology, etc. ) for full set of lithium battery producing line to help clients to establish a factory of lithium battery.
Our group also has a subsidiary exporting company -- Linyi Dake Trade Co., Ltd, mainly deals in all exporting business of group. We have a professional and experienced exporting team to supply perfect services for you. Through trading company, all of our products and services such as materials, equipments, technology, etc. Will be offered to clients from all over the world.
We are confidence on our quality and service. And we ensure that we will offer you the best services based on our specialty and empressement. Our aim is to be the comprehensive company dealing with one-stop services of lithium battery in the world.
Welcome batteries manufacturers all over world visit our company, and your inquiry will be appreciated.
