Pet Film for The Use of Backing Materials of Solar PV

Name: Pet Film for The Use of Backing Materials of Solar PV
Brand: all-electronics-online.com
SKU: 714051082
Availability: InStock
Rating: 5 (129 reviews)

Price:	Negotiable/Ton
Min Order:	1/Ton
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	6E25
ID Of The Core:	50 or 76 mm
Product Type:	Film,Roll
Tensil Strength:	Different with Thickness
Hardness:	Soft
Smell:	No.
Sample Size:	A4 or Others
Application:	Motor
Type:	Insulation Film
Chemistry:	Hybrid Insulation
Thermal Rating:	E 120
Maximum Voltage:	10KV~20KV
Material:	Pet
Brand:	Toyo

Product Description

Packaging & Delivery

Packaging Details	Standard Package: Wooden Pallet, Wooden Case.
Delivery Detail	7-10 days

Features and Applications

Semitransparent, and with good mechanical capacity, good heat resistance, good dimentional stability,good electrical insulation property,good fire-resistance, good resistance to water vapor permeability,good processability, can be used for backing materials of solar pv.
When slitting and using, crack at the edge, scratches on surface, greasy dirt and dust should be avoided.

Property

Properties	Unit	Requirements					Test Method
		Nominal Thickness (micron)
		125	150		188	250
Tensile Strength Linear Lateral	Mpa	180 180	175 175		170 170	160 160	GB/T 13542.2 -2009
Elongation at Break Linear Lateral	%	115 110	115 115		120 115	125 110
Shrinkage Linear Lateral	%	0.8 0.3	0.8 0.3		0.8 0.3	0.8 0.4
Power Frequency Electrical Strength	v/ μm.	95	90		85	85
Water Vapor Permeablit-y	g/m² 24h	2.1		1.8	1.6	1.4	GB/T 21529-2008
Voltage for partial discharge	VDC	---		---	810	1040	IEC60664-1-2007
Fire Resistance	---	VTM-2					ANSL/UL94-2009
Infiltration Tension	MN/M	52					GB/T 13542.2 -2009
Accelerate-d Life	h	40-72					121centigra-de,2 barometric pressure
A Heat resistance grade is E class. B Standard NO. is Q/DSJ-357-2009

Store

Keeping below 40 centigrade, and keep away from combustion source, heat source, and do not receive direct sunlight, sheld life since manufacturing data is 13 months; if after corona treatment, it will be 6 months.

Packaging & Shipping

Normally the out - packaging for the goods is wooden pallet or wooden case, we can deliver it by air or by ship.
Airport: Beijing, Tianjin, Qingdao, Nanjing, Shanghai, Guangzhou, Shenzhen
Sea Port: Tianjin,Qingdao, Shanghai, Ningbo, Guangzhou
Packing Type Photo is as the following:

We are major in insulation material of various classes, from B to F, and from F to H, TOYO'S products are widely used in Motors, Generators, Welders, Electrical Heaters, and etc. And provide assurances for their long time, stability work.

The test results of from SGS Shanghai branch indicate that the TOYO's products are in conformity with EU RoHS Directive 2002/95/EC and subsequent revision directives. And our product conforms to REACH regulation's requirements (the newest version) of European Union after tested, and also passed UL certification of American and Canada.

" TOYO" Team was composed of many senior electrical engineers, and insist on response to every client's enquiry 100%. Maintaining good cooperative relationship with main manufacturers in domestic for long term, and this provides " TOYO" With stable product quality; Reasonable prices; Timely supply.

We started to do the foreign trade since 2014, because of the good faith, now we have had so many customer from home and abroad. We are also planning to making the investment to enhance the relationship with our key suppliers, and meet our customer's requirements.

Welcome you to contact us and discuss business at any time.
