| Prod Model: |
HA |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Material: |
ABS & PC |
| Rated Voltage: |
AC220V,50Hz |
| Main Current: |
60A to 250A |
| Ingress Protection: |
IP65 |
| Branch Circuit Number: |
4,6,8,10,12 |
| Current Of Main Circuit: |
60A to 250A |
| Standards: |
GB3836, IEC 60079 |
| Branch Current: |
1 a to 60A |
| Name: |
Box Manufacturer |
| Type: |
Distribution Metering Box |
| Structure: |
Protection |
| Shell Protection Grade: |
IP65 |
Product Description
box manufacturer
1,Exd Explosion proof distribution panel distribution boards
2,Main current: 60A to 250A
3,Branch current:1 A to 60A
BXM(D) Explosion Proof Illumination ( Power) Distribution Boards distribution box , distribution panel,
Application
Designed for
Explosive atmosphere Zone 1, Zone 2
Combustible dust Zone 20, Zone 21, Zone 22
Designed for
Groups IIA,IIB,IIC
Temperature classes T1~T6
Design for sites with explosive atmosphere such as petroleum exploitation, refinery, storage, chemistry, medicine, textile, printing, military and military facilities ,etc.
Used for power distribution in illumination or power circuit.
Features
Compound structure, main compartment is of flameproof type connection compartment is of increased safety type.
Modular design, each circuit can be combined freely.
Built-in high breaking mini circuit breaker or molded case circuit breaker, can be controlled on-off via handle on enclosure.
With on indicating lamp.
With overload, short circuit protection, and leakage protection function can be made as per request.
Can be used for on-off in illumination circuit or power circuit or combination of illumination circuit and power circuit breaker.
Can be specially made as per request.
Steel pipe and cable wiring.
Technical Specification
Compliance with: GB 3836.1,GB 3836.2,GB 3836.3,IEC60079-0,
IEC60079-1, IEC60079-7, EC61241-1-1
Explosion protection: ExdeIIBT6, DIPA20TA, T6
Rated voltage: AC 220/380V
Rated current of main circuit: 60A~250A
Branch circuit number: 4,6,8,10,12
Rated current of branch:1A,3A,5A,10A,15A,20A,25A,32A,40A,50A,60A
Ingress protection: IP65
Corrosion resistance: WF1
Cable entries Specification: G1/2"~G3"
Cable's outer diameter:Φ6mm~Φ55mm
Cable entries direction: downwards inlet and downwards outlet or upwards outlet,
normal type is downwards inlet and outlet, other requirements please indicate.
