Power Capacitor Electrolytic Capacitor 15000UF 350V
| Price: |
US $ 0.04-0.05/Piece |
| Min Order: |
5000/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
15000UF 350V |
| Operating Temperature Range: |
-40~105 Degree |
| Load Life: |
2000 Hours 105c |
| Rated Voltage: |
350V |
| Type: |
Aluminum Electrolytic Capacitor |
| Application: |
Automobile |
| Package Type: |
Through Hole |
| Capacitance: |
15000UF |
| Usage: |
for High Quality, Reliability Application, High CV |
Product Description
Power capacitor electrolytic capacitor 15000UF 350V
Features
*OEM available
*Withstand 350V
*Low disspation factor
*Operating Temperature Range:-40~105 degree
Specifications
| Item | Characteristics | |
| Temperature | -40~+105°C | | -25~+105°C | |
| Voltage | 6.3~100VDC | | 160~450VDC | |
| Capacitance | 1~15000μF | | 1~470μF | |
| Leakage Current | I=0.01CV or 3(μA) whichever is greater. | | I=0.03CV+10(μA) | |
| (After rated voltage applied for 2 minutes) | |
| Capacitance | ±20% at 120Hz, 20°C | |
| Dissipation Factor | WV | | 6.3 | | 10 | | 16 | | 25 | | 35 | | 50 | | 63~100 | | 160~250 | | 350~450 | |
| tanσ | | 0.26 | | 0.22 | | 0.18 | | 0.16 | | 0.14 | | 0.12 | | 0.10 | | 0.15 | | 0.20 | |
| Tanσ shall be added 0.02 with increase of every 1000μF, when capacitance is over 1000μF. | |
| Stability & Impedance | WV/z(120hZ) | | 6.3 | | 10 | | 16 | | 25~100 | | 160~250 | | 350~450 | |
| Z-25°C / 20°C | | 4 | | 3 | | 2 | | 2 | | 4 | | 4 | |
| Z-40°C / 20°C | | 8 | | 6 | | 4 | | 3 | | - | | - | |
| Load Life | Meet following requirements after applying rated voltage 2000hrs at 105°C. | |
| Capacitance Change | | Within ±20% of initial value | |
| Dissipation Factor | | Not more than 200% of the specified value | |
| Leakage Current | | Initial specified value or less | |
| Shelf Life | Meet the same requirements as endurance after applying without voltage for 1000hrs at 105°C. | |
| Applications | For high quality, reliability application, high CV product. | |
Product Range
| Series | Items |
| Vertical Chip Series Capacitors | FV, SV, ZV |
| General Type Series Capacitors | SK, SE, SH |
| Low Profile Series Capacitors | S5, H5, D7, H7 |
| Non-Polar Series Capacitors | RN, SN. |
| Low LC & Impedance Series Capacitors | SB, SC, SJ, SZ |
| Slim Capacitors Series Capacitors | TH, TG, TP |
| Snap-in Series Capacitors | LH, LG, LF, LJ |
Since 1985, SEMG is one of the leading electronic component manufacturers located in Baoan District, Shenzhen City, China, and has been specializing in designing, researching, developing, manufacturing, exporting and processing professional Aluminum Electrolytic Capacitors, Magnet material, PCBA. Now it's becoming the most reliable and famous supplier in China.
SEMG Electrolytic Capacitors
We offer over 23 series 10 thousand various kinds of capacitors products and monthly output up to 2 millions pieces.
*General Purpose aluminum Electrolytic Capacitors
*Low ESR & High Frequency aluminum Electrolytic Capacitors
*Low Impedance &High Ripple aluminum Electrolytic Capacitors
*Low ESR &Long load life aluminum Electrolytic Capacitors
*High ripple &long load life aluminum Electrolytic Capacitors
*snap-in aluminum Electrolytic Capacitors
*SMD Capacitor
*Solid Capacitors
The capacitors we produced widely used for power supply and LED driver, Ballast, Adaptet, SMPS, Home appliances etc. The annual output is more than 800million electrolytic capacitors a year.
SEMG is a ISO Certificated company, the quality of us had pass, RoHS, Reach, CE etc. And we can design the quality products as the customers needed!
SEMG Smartnoble EMC shielding Material
Smartnoble is a subsidiary company of SEMG, focus on the manufacturing and supplying EMC shielding material with silcone rubber, customized shape, welcome to visit http://www.smartnoble.cn/ for details.
SEMG Printing & Acoustic Fabrics
SEMG provides the high tension and low elongation of polyester mesh, with SGS and MSDS certificates, and applicable to the high precise printing for the industries of printed circuit boards, touch panel, glass and textile, cellphones etc. And also providing the advanced acoustic fabrics, which widely used in the protection of acoustic devices, and perform well to meet customer's demand, with its accurate holes and air current control, and its excellent stability to the different environment.
SEMG PCB Fabrication:
SEMG produces the samples and small volume of High layer and rigid-flex PCB, and big volume of low techology PCB.
1) Manufacturing facilities in China for a total capacity of over 4.0 million FT2/month, building area: 500, 000sq. FT, and typical PCB Equipment includes: Mitsubishi Laser Machines, Horizontal Copper plating, Horizontal Silver plating, Heavy Gold plating, Inner Finger beveling, and Automatic Appearance Inspection, etc.
2) Process Capability: Trace Width 3/3mil for volume production, 2/2mil for prototype, min. Mechanical hole 0.15mm, min. Laser via: 0.1mm.
3) Broad product range with expertise in:
Prototype, medium and high volume production of single-side, 2L, 4L to max. 28L.
Max. HDI capability (4+N+4) PCBs.
High frequency and high performance PCBs
Heavy copper PCBs (up to 12oz inner copper)
Aluminum-based PCBs
4)Certificates: ULNo.: E96016, ISO9000-, ISO/TS16949(Automative),
ISO13485 (Medical) -certified and Bellcore-compliant(Telecom).
5) Global support across different continents.
Other service: R&D of wireless modules
SEMG is focus on the researching and development of wireless modules and products, with WiFi, ZIGBEE, and Blue tooth solutions.
