Product Description
Specifications:
High Voltage XGN2 Type
electrical switchgear 12kV
electrical switchgear 50/60Hz
ISO
power distribution metal clad switch cabinet |
China supplier Customized power distribution equipment XGN2 electrical switchgear
Product Description
Modular Metal-enclosed power distribution equipment XGN2 electrical switchgear
XGN2 enclosed XGN2 electrical switchgear is applied to receive and distribute the electrical energy in 3, 6, 10KV three-phase AC 50HZ system, especially for the frequently operated occasion. Its busbar system is a single busbar (which can derive the single busbar with bypass and double busbar structure).
The main switch of the enclosed high voltage outdoor electrical cabinet applies ZN28A-10 series vacuum circuit breakers, equipped with CD117 series of electromagnetic operating mechanism and CT19 series of spring operating mechanism. Using GN-30 rotary isolating switch. |
Product Standard
The enclosed high voltage outdoor electrical cabinet is in line with the requirements of the National Standards GB3906 3-35KV AC Metal-enclosed Switchgear Cabinet and the National Standard IEC298, and there are two proposed "five anti" interlocking functions.
|
Application
HV enclosed high voltage outdoor XGN2 electrical switchgear is applicable to :
the load center of powder distribution station
prefabricated substation in urban residential area,
high-rise building,
large public buildings,
factories and enterprises with three-phase AC 50Hz. |
Features
1. Metal-enclosed and separately arranged, with high protection Category
2. Enclosure with Front -Cabinet protection and back-cabinet protection, the Board can be arranged and fixed along with the wall to save the spaces
3. Protection Category of enclosure reaches to IP4X,
4. Elec.Line Cabinet with full spaces for mount and arrange in-coming and out-going lines for the convenience of Fixing, protecting and maintaining |
| 1 | three-phase AC 50HZ HV XGN2 electrical control cabinet for electrical works is made of coated aluminum zinc plate after multiple bending assemblies. |
| 2 | All operations were carried out in the cupboard door closed. |
| 3 | High protection level can prevent the clutter and pest invasion. |
| 4 | Simple and effective "five prevention", locking to prevent wrong operation. |
| 5 | High Voltage Power Distribution Switchgear can be equipped with VS1 (ZN63A) or used VD4 type vacuum circuit breaker according to user requirements. |
| 6 | replacement of the circuit breaker is simple,handcart interchangeability is good. |
| 7 | Switchgear can be installed against the wall, serviced in front, reduce area. |
| 8 | cable room space is abundant,can connect a plurality of cables. |
| 9 | Rapid grounding switch is used for ground and loop short circuit. |
| 10 | Circuit breaker rooms, relay room, cable room can be separately installed heater according to user requirements,can prevent the occurrence of condensation and corrosion |
| 11 | Circuit breaker room, cable room can be installed the lighting device according to user requirements, in order to facilitate maintenance and maintenance. |
