Premium 3D V1.4 High Speed Ethernet 1080P RoHS HDMI Cable

Prod Model:	HDMI-035
Cable Length:	6FT
Cable Color:	Black
Cable Material:	PVC
Cable Conductor:	28AWG Copper
Cable Plug:	19pin
Cable Od:	7.0mm
Cable Package:	Poly Bag, Blister and Gift Box
Cable Certification:	FCC, Ce, RoHS
Application:	Monitor
Color:	Black
Type:	Twisted Pair
Connector:	HDMI
Certification:	CE
Brand:	OEM

Product Description

Premium 3D V1.4 High Speed Ethernet 1080P Rohs HDMI Cable

SPECIFICATIONS:
(1)    2×HDMI 19PIN, male connectors
(2)    Gold plated connectors
(3)    Nylon protection layer
(4)    Digital transfers at rates up to 10.2Gbps
(5)    High purity OFC conductor
(6)    UL20276 AWG(1P+D+MY)×4+5C+1P+AEB
(7)    All materials are RoHS complaint

FEATURES
(1)     HDMI to HDMI cable that is suitable for use in HDTV, home theater, DVD player, projector, PS3, and other HDMI devices
(2)    24k gold-plated connector resists corrosion and ensures an optimum connection for maximum signal transfer
(3)    High pure OFC conductor for maximum conductivity and reliability
(4)    High density triple shielding for maximum rejection of EMI and RFI
(5)    Compatible with multiple audio formats from stereo to multi-channel sound
(6)    Transfer digital audio and video signals at warp speed of 10.2 gigabytes per second

ELECTRICAL
(1)    100% open and short test
(2)    Conductor resistance: 2 OHMS Max
(3)    Insulation resistance: 5 MEGOHMS Min
(4)    HI-POT:DC300v/0.01s
(5)    HDTV-DVD test: 1080P

PACKING
(1)    Double blister
(2)    Electrostatic prevention bag
(3)    Poly bag with sticker

Shenzhen Good Phase hui electronics has 19 years experience in production, we have more than 40.000 square meter workshop with more than 1000 experienced staffs.

HDMI Version	1.4V/2.0V
Data transfer speed rate	10.2 Gbps
Support resolution	480p to 1080p and up to 4K×2K.3D video
Conductor	TC/OFC/BC/CCS
Connectors	PVC
Plugs	24K gold plated/Nickle plated
Cable Gauge	30AWG/28AWG
