Pressure Transducer(sputtering Filmed )

Name: Pressure Transducer(sputtering Filmed )
Brand: all-electronics-online.com
SKU: 607702585
Availability: InStock
Rating: 4.4 (40 reviews)

Price:	Negotiable
Min Order:	1

Contact Supplier

Showroom Product Company Profile

Prod Model:	Pt 200 series

Product Description

Sputtering Film
Import thin-film sputtering chip, suitable for pressure measuring in oil well.
1. Capacity Range: 0~1-150MPa
2. Comprehensive Precision: 0.1%FS, 0.2%FS
3. Output Signal: 1~1.5mV/V
4. Use Temp Range: 0~175º C
5. Temp Effect on Zero: ≤ 0.005%FS/º C
6. Input Resistance: 1300~1500Ω
7. Safe Overload: 150%F. S
8. Excitation Voltage: Transducer 10V(6~12)V
9. Time of Response: 0.1S
10. Electric Connection: Hi-Temp Wires output
11. Process connection: M10χ 1 M12χ 1
12. Seal: Double ring with gasket

Guangdong South China Sea Electronic Measuring Technology Co., Ltd. (SCS)is located at Dongguan City, Guangdong Province, Where is the manufacture centre of China. Established in 1992, it specializes in developing and manufacturing advanced load cells, force sensor, Torque sensor, axle weigher, wheel weigher, pressure transducer based on strain-gages. We also manufacture custom designed load cells and weighing system whatever our customers can dream up. Some of our products have "OIML" and European approved "CE" mark. Hope we will establish a long term business-ship with you.
