| Prod Model: |
XJY-PCB 217 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Solder Mask: |
Green Blue Red White Biack etc |
| Test: |
Aol |
| Board Thickness: |
1.6mm |
| Copper Thickness: |
1oz |
| Layer: |
1 to 16 |
| Color: |
Green, White, Black, Ect |
| Min Hole Size: |
0.2mm |
| Min Line Width: |
0.1mm |
| Min Line Spacing: |
0.1mm |
| Surface Finish: |
HASL, Immersion Gold, OSP |
| Type: |
Rigid Circuit Board |
| Dielectric: |
CEM-3 |
| Material: |
Fiberglass Epoxy |
| Flame Retardant Properties: |
V0 |
| Base Material: |
Fr4 |
Product Description
WELCOME TO XJY--------- Shenzhen Xinjiaye Electronics Technology Co., Ltd is a professional pcb manufacturer has over 10 years experience. We are able to offer 1 to 24 Layer PCB, ranging from pcb produce, components purchase, pcb assembly, pcb copy service.Our products are widely used in communication apparatus, automobile electronics, auto parts, computers, medical devices, light systems, outdoor systems, network devices and consumer electronics class fields.Quick Details
Place of Origin: |
Guangdong, China (Mainland) |
Brand Name: |
XJY |
Model Number: | XJY-PCB 217 |
Number of Layers: |
1-16 layers |
Base Material: |
FR-4 |
Copper Thickness: | 1~5OZ |
Board Thickness: |
0.4--3.2mm |
Min. Hole Size: |
0.2mm |
Min. Line Width: |
0.1mm |
Min. Line Spacing: |
0.1mm |
Surface Finishing: |
immersion gold |
Color: |
Green,blue,black,red,yellow,white, Matt Color |
Surface Finishing:: |
HASL,Immersion Gold/Silver, OSP |
Other treatment: |
Carbon treated, peelable mask,Gold finger |
PTH Tolerance:: |
+/- 0.075 mm |
NPTH Tolerance:: |
+/-0.05 mm |
Class Standard:: |
IPC-6012 Class -II |
Size Tolerance:: |
+/-0.12 mm |
Origin:: |
China |
Flammability:: |
UL 94V-0 |
Impedance control: |
Yes |
Specifications
1. UL, RoHS, ISO9001
2.OEM&ODM are welcome
3.pcb manufacturer
4.Competitive Price,High Quality
5.HDI PCB, 6 Layer PCB, PCB
Features
* Low water absorption rate
* Hard to be deformed
* High mechanical strength
* Good electric performance wether under the moist or dry environment, Flame retardant grade could reach 94-V0
* High temperature resistant,high dielectric performance and mechanical processing performance.
PCB manufacture and PCB assembly
* PCB board file with parts list provided by customer
* PCB board made, circuit board parts purchased by us
* PCB board with parts assembled
* Electronic testing circuit board or PCB
* Fast delivery, anti-static package
* RoHS Directive-compliant, lead-free
Testing procedures
* Visual Inspection
* Flying probe
* Impedance control
* Solder-ability detection
* Digital metallograghic microscope
*AOI (Automated Optical Inspection)
Technology capability
| Items | Single/Double-sided Board/Multilayer Board/FPC(1-24Layer) |
| Base Materials | FR-4(High TG 150°-170°),FR1,Aluminum,CEM-3,BT,94vo |
| Finish copper thickness | Outer 6 OZ,Inner 4 OZ |
| Surface finish | ENIG, ImAg, ImSn, OSP, HASL,Plating gold |
| Finished Board Size | Max Double-sided Board | 640mm χ 1100mm |
| Max Multilayer Board | 640mm χ 1100mm |
| Finished Board Hole Size (PTH Hole) | Min Finished Board Hole Size | 0.15mm |
| Conductor Width and Spacing | Min Conductor Width | 0.01mm |
| Min Conductor Spacing | 0.01mm |
| Thickness of Plating and Coating Layer | PTH Wall Copper Thickness | >0.02mm |
| Tin Solder Thickness ( Hot Air Leveling ) | >0.02mm |
| Nickl/Gold Thickness | For customer special need |
| Nickl Plating Layer | >2um |
| Gold Plating Layer | >0.3um |
| Bare Board Test | Single Side Test | Max Test Point | 20480 |
| Max Board Test Size | 400mm χ 300mm |
| Double Side Test | Max Test Point | 40960(General Use) |
| 4096(Special Use) |
| Max Board Test Size | 406mm χ 325mm |
| 320mm χ 400mm |
| Min Test pitch of SMT | 0.5mm |
| Test Voltage | 10-250V |
| Mechanical Process | Chamfer | 20°, 30°, 45°, 60° |
| Angle Tolerance | ± 5° |
| Deepness Tolerance | ± 0.20mm |
| V-Cut Angle | 20°, 30°, 45° |
| Board Thickness | 0.1-3.2mm |
| Residues Thickness | ± 0.025mm |
| Cell Paraposition Precision | ± 0.025mm |
| Tolerance of Out-shape Process | ± 0.1mm |
| Board Warp | Max Value | 0.7% |
| Optical Plotting | Max Plotting Area | 66mm χ 558.8mm |
| Precision | ± 0.01mm |
| Repetitive Precision | ± 0.005mm |
