Printed Circuit Board&SMT PCB Board

Name: Printed Circuit Board&SMT PCB Board
Brand: all-electronics-online.com
SKU: 676806842
Availability: InStock
Rating: 4.6 (76 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB
Min Order:	200/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BP003
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Rigid Circuit Board
Dielectric:	FR-4
Material:	Fiberglass Epoxy Resin + Polyimide Resin
Flame Retardant Properties:	HB

Product Description

About us:
Our company was established in 1992 with about 3,000 employees,total land area up to 101,000m², and floor area up to 81,000m². We specialize in PCB manufacturing for more than 20 years.

With foresight management, we insist on "providing excellent quality products". We provide nearly error-free products and overall structured service in order to satisfy customer's needs.

Year Item	2015	2016E
Year Item	2015	Mass Production	Sample
Max. Multilay ers	20	20	24
Board Thickness Tolerance (mil/mm)	50±3mil / (±0.076mm); 14±2mil / (±0.05mm);	50±3mil / (±0.076mm); 14±2mil / (±0.05mm);
Min. hole size (mil)	Mechanical 6mil (0.15 mm), Laser 4mil (0.10 mm)	Mechanical 6mil (0.15 mm), Laser 4mil (0.10 mm)	Mechanical 6mil (0.15 mm), Laser 3.5mil (0.089 mm)
Finished Aspect ratio	12:1.	12:1.	16:1.
Min. line Width/Space (mil)	2.0/2.0mil; (0.050/0.050 mm)	2.0/2.0mil; (0.050/0.050 mm)	1.6/1.6mil;(0.040/0.040mm)
Impedance (ohm)	+/-10%	+/-10%	+/-7%
Dif f erential Impedance (ohm)	+/-10%	+/-10%	+/-7%
Gold Finger thickness(u"/um)	80u" (2um)	80u" (2um)	80u" (2um)
Router tolerance	±3.0mil (0.076mm)	±3.0mil (0.076mm)	±2.0mil (0.051mm)
Surf ace treatment	ENIG,H/G plating,OSP,Immersion sliver		ENIG,H/G plating,OSP,Immersion sliv er,Immersion Tin,ENEPIG
Application / Lamination
Standard and extended	FR4(TG140-180°),ANTI-CAF,Halogen Free, Low z-axis expansion(Lead Free)
Special perf ormance	High TG(BT)		High TG(BT),Low loss,FPCB material
High f requency	PTFE,Ceramic

Brain Power's Strength:

Excellent quality stability.
Excellent process and handling control. (Thus impedance yield can achieve to 98% !)
High customer satisfaction.
Thin Board Production with 2 mils core.
Different Impedance technique leader in the RAM module market.
Tight board thickness tolerance(+/- 3 mils) control.

Before quote, please offer:

Gerber file
Base material: FR4/ AL/ FPC/ CEM-1/ CEM-3/ 94v0/ Rogers
Board thickness
Surface treatment
Copper thickness
Color of solder mask and silkscreen

Shenzhen Tengyuxin Technology Co., Ltd is a professional PCB & PCBA manufacturer which specialized in manufacturing SS, DS, HDI and multilayer PCB. Our modern factory is located in Qingyuan Guangdong which has more than 3000 staffs and 101, 000 square meters workshop. We can provide all-in -one service ( R&D, manufacturing and sales) for you
