Printed Circuit PCB for Power Board

Name: Printed Circuit PCB for Power Board
Brand: all-electronics-online.com
SKU: 731585712
Availability: InStock
Rating: 4.6 (51 reviews)

Price:	US $ 1/Piece
Min Order:	1/Piece
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	FD
Type:	Rigid Circuit Board
Dielectric:	FR-4
Material:	Paper Phenolic Copper Foil Substrate
Flame Retardant Properties:	V1

Product Description

Right Option of Aluminum PCB Manufacturing with Assembly Services
High Heat Tolerance Aluminum PCB Board for LED

The following table presents some of our Aluminum Core materials:

Items	Performance Index (Measured value)
Peeling strength (n/mm)	1.8
Insulation resistance (ω)	>1*10 g
Breakdown voltage (vdc)	>2 k
Soakable soldering (°C/m)	280°C / 260°C, 1 min, no bubble & delamination
Thermal conductivity (ω/m-k)	>0.8
Thermal resistance (°C/ω)	< 1.2
Combustibility	fv-o
Dielectric constant (1mhz)	4
Dielectric loss angle (tangent)	0.03

Please check our Aluminum core PCB manufacturing capabilities in the following table:

Features	Capability
Quality Grade	Standard IPC 2
Number of Layers	4 - 24layers
Order Quantity	1pc - 10000+pcs
Build Time	2days - 5weeks
Material	Aluminum core (Domestic 1060), Copper core, FR4 covering
Board Size	Min 66mm \| Max 610610mm
Board Thickness	0.8mm - 5.0mm
Copper Weight (Finished)	0.5oz - 10.0oz
Min Tracing/Spacing	4mil/4mil
Solder Mask Sides	As per the file
Solder Mask Color	Green, White, Blue, Black, Red, Yellow
Silkscreen Sides	As per the file
Silkscreen Color	White, Black, Yellow
Surface Finish	HASL - Hot Air Solder Leveling
	Lead Free HASL - RoHS
	ENIG - Electroless Nickle/Immersion Gold - RoHS
Min Annular Ring	4mil
Min Drilling Hole Diameter	6mil
Other Techniques	Countersink holes
Other Techniques	Screw holes

About Us
As a service-leading PCB manufacturing and PCB assembly (PCBA) partner, NOD Electronics strives to support international small-medium business with 10+ years engineering experience in Electronic Manufacturing Services (EMS). Our headquarter is located in Guangzhou, China. We have 10,000 square meters plant, 287 employees and 42 engineers, monthly capabilities of 15,000 square meters PCB design & fabrication and 80 million spot SMT. We were approved by ISO9001-2008, TS16949, UL, CE, RoHS.

We are offering PCB manufacturing and assembly services to following big customers all over the world.
High Heat Tolerance Aluminum PCB Board for LED

Your aluminum PCB demand will be perfectly handled by our advanced production lines and responsive team!
High Heat Tolerance Aluminum PCB Board for LED

Our experienced, knowledgeable engineering team takes the time to examine every custom PCB design before production to ensure it meets your specifications. Our custom PCB manufacturing capabilities enable you to get high-quality aluminum PCBs

Found PCB, established in 2005, Shenzhen Found Printed Circuit Board Co., Ltd. is part of Found group. Found PCB dedicated to provide one-stop service, to meet highest technology, quality and quick turn over challenges with lowest cost.

Shenzhen Found Circuit Board Co., Ltd supply all kinds of PCBs more than 10 years. Products including Rigid PCB (1-20 layers), flex PCB(1-4 layer), metal core PCB, Rigid-Flex PCB, especially in the metal core PCB, they use widly in the LED lighting.

A lot of comepays from Europe and North American buy from Found, cause we are the source, we can offer very good price, we think we can save a lot of your purchasing cost.

We also offer PCB solution. Such as Rigid-flex PCB, a lot of factories in China can not made this kind of the rigid-flex PCB. But Found is good at this...

With several year's rapid development, the production capability of our factory reachs 25, 000 square meters with over 500 employees and 180, 000 sq. M production area. Found PCB has been certified by International Quality System IS09001, ISO14001, TS16949 and UL (E361831).

We welcome the every opportunity to working for you. We have the good name in the PCB market.
