Professional Factory Nfin 2p High Quality Residucal Operated Current Circuit Breaker

Name: Professional Factory Nfin 2p High Quality Residucal Operated Current Circuit Breaker
Brand: all-electronics-online.com
SKU: 730938772
Availability: InStock
Rating: 4.8 (92 reviews)

Price:	Negotiable/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	NFIN-2P
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Electric Type
Speed:	Normal Type Circuit Breaker
Arc-extinguishing Medium:	Vacuum
Installation:	Fixed
Structure:	MCB
Poles Number:	2
Certification:	CCC

Product Description

Application:

The Residual Current Device (RCD),Residual Circuit Breaker NFIN is in conformity with the standard of IEC61008.

It can cut off the fault circuit immediately on the occasion of shock hazard or earth leakage of trunk line.

Thus it is suitable to avoid the shock hazard and fire caused by earth leakage.
NFIN RCD is mainly suitable for using in varieties of plants, enterprises, buildings, constructions, commerce,

guesthouse and families. It can be used in circuit of 1 phase 230V and 3 phase 400V 50/60Hz..

Technical data

Number of Poles	2P,4P
Rated Current(A)	16,20,25,32,40,50,63,80,100
Rated Residual Operating Current (In)(mA)	30,100,300,500
Rated Residual Non-operation Current (Ino)(mA)	≤0.5In
Rated Voltage (V)	AC230/400
Residual Current Off-time	≤0.1S
Short Circuit Capacity(Icu)	3000A
Endurance	4000
Protection Degree	IP20
