Shenzhen Winsafe Technology Co., Ltd. >> PTZ Speed Dome Cameras Keyboard Controller

PTZ Speed Dome Cameras Keyboard Controller

PTZ Speed Dome Cameras Keyboard Controller
Price: Negotiable/Piece
Trade Terms: FOB,CIF,EXW
Min Order: 1/Piece
Pay Type: T/T,Western Union
Prod Model: CKB-11H
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model No.: Ckb-10h
Communication Frequence: 2400, 4800 ,9600 ,19200BPS
Protocol: Pelco-P/Pelcod/Hcdvr/Dh
Output And Input: Sdi/HDMI Input, HDMI Output
Weight: 252g
Advantage: 11 Years Producation Experience
Warranty: 2 Years
Lead Time: 3-7 Work Days
Signal Transmission: IR Remote Control
Certification: CE
Universal: Universal
Transmission Distance: >100m
Voltage: 12V
Material: Plastic
Application: Camera Controller
Battery Type: Power Supply

Product Description

PTZ Speed Dome Cameras Keyboard Controller

Features
RS485 Bus line, and a keyboard can Max. connect 31 domes in direct control mode
Compatible with all kinds protocols
Control the Iris Focus & Zoom
Support set and call the preset, run the scanning the pattern and the tour
Support control the matrix and through matrix to control the speed dome
Equipped with the 3D Joystick and a LCD screen
SDI/HDMI input, HDMI output
Built-in battery, output DC12V/1A

Specification
Model No.CKB-10H
Communication ModeRS485x1 IR Emission
Communication Frequence2400, 4800 ,9600 ,19200bps
Communication InterfaceRS485,RS422 Emission1,2Km
ProtocolPelco-P/PelcoD/HCDVR/DH
Screen3.5" Digital LCD Monitor
HumiditiesLess than 90%
Operation Temperature-10°C ~ +50°C
Operation VoltageDC 12V±10%
Operation Consumption150mA
Measure168mm x 86mm x 28mm(L x W x H)
Weight252g
MaterialABS Plastic Cover


Originally founded in 2002, WINSAFE Technology Co., Ltd. is a private high-tech entity specialize in CCTV and video surveillance products. We design\produce and sell all kinds of CCTV products and video conference products that are of high quality\good service and competitive prices to overseas customers

We manufacture a full-line of innovative CCTV and video surveillance products, such as Weather Proof PTZ Cameras for fast deployment, which can be installed in vehicle systems, surveillance tower, systems, rapid deployment case and also on tripods, IP & Analog PTZ Cameras, IR PTZ Cameras, HD-SDI IP & Analog PTZ Cameras, Household IP Cameras, DVR & NVR, PTZ Controller, Dome Cameras, Video Conference Cameras etc.

At present, The Company owns a 3, 000 square meters factory with 200 employees, which includes16 R&D engineers with rich experience in the line of security and IT products, . We promote new technologies every 6 six month, also we can produce the products at customer's request for we have a complete manufacture and quality managing system of products.

Our products are widely applied in surveillance systems of Bank, airport, traffic, supermarket, apartment, office, army etc. We serve for more than 30 countries, such as USA, Canada, Mexico, UK, German, Switzerland, Italy, Spain, France, Japan, Vietnam, Indonesia, Malaysia, Singapore, etc. Meanwhile, we are providing ODM/OEM services to global brands.
