Pure Sine Wave DC 12V/24V/48V to AC 110V-240V Inverter Without AC Charge
| Price: |
US $ 50/Piece |
| Trade Terms: |
FOB,CFR,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Paypal,Money Gram |
| Prod Model: |
300w-6000w |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Input Volt: |
DC 12V /24V/48V |
| Output: |
AC 11V/220V |
| Wave: |
Pure Sine Wave |
| Output Frequency: |
50/60Hz |
| Over Volt Protect: |
Yes |
| Low Volt Protect: |
Yes |
| Over Load Protect: |
Yes |
| Over Temp Protect: |
Yes |
| Short Circuit Protect: |
Yes |
| Function: |
with AC Charge or Without AC Charge |
| Phase: |
Single |
| Type: |
DC/AC Inverters |
| Power Source: |
Solar Power |
| Output Power: |
201 - 300W |
Product Description
1. Pure sine wave output(THD<3%)
2.Power ON-OFF switch
3.Thermo control cooling fan
4.Two-color indicator display power and fault status.
5.Protections: short circuit,overload,over/low temperature.
6.Battery voltage, over battery voltage,lack-voltage alarm.
7.Topology: Microprocessor
8.With AC charge
9.Approvals: ROHS/CE
10.1 year warranty.
Package and shipping
Company information 1.Q:Are you a factory or trading company? How many people work in your company?A : We are a factory and a trading company together Now we got 500 workers till this year.2.Q:Where is your factory located? How can I visit there? A:Our factory is located in Wenzhou City, Zhejiang Province, China, about 1.5 hours from Guangzhou by air . All our clients, from home or abroad, are warmly welcome to visit us!FAQ:1. What is the Inverter ? Inverter is an electronic equipment that turn 12v/24v/48v dc into 110v/220v ac.
2. How many kinds of output wave form for inverters? 2. Two kinds. Pure sine wave and modified sine wave. Pure sine wave inverter could provide high quality AC and carry various loads, while it requires high tech and high cost. Modified sine wave inverter load poorly not carrying inductive load, but the price is moderate.3. How do we equip an appropriate inverter for battery? Take a battery with 12V/50AH as an example. Power equal current plus voltage then we know the power of battery is 600W. 12V*50A=600W. So we can choose a 600W power inverter according this theoretical value.4.What is the MOQ ? We have international retail store, so our MOQ is 1 piece.5. How can I get some samples? A: We are honored to offer you samples. 6: What's your brand ?A: . SmunIf you have good quantity,it absolute no problem to do OEM ,ODM.Our servicesIf you can cooperate with us, we will be honored and you will benefit from: * The good construction warranty1~2 years * Your client satisfied on the right schedule and quality * Your can get good reputation from your market and obtain more orders * Our professional service before and after sale * The free inverter samples after your first 3 orders * The reasonable price * Any questions from you are welcome and will be replied in 24 hours
| Pure Sine Wave Inverter (PS series) |
1. Pure sine wave output(THD<3%)
2.Power ON-OFF switch
3.Thermo control cooling fan
4.Twocolor indicator display power and fault status.
5.Protections: short circuit,overload,over/low temperature.
6.Battery voltage, over battery voltage,lack-voltage alarm. 7.Topology: Microprocessor 8.Approvals: ROHS/CE 9.1 year warranty. |
| Technical Parameter |
|
|
|
|
|
| Specification | PS300 | PS400 | PS500 | PS600 | PS800 |
| Continuous Output Power(W) | 300 | 400 | 500 | 600 | 800 |
| Spike Output Power(peak)(W) | 600 | 800 | 1000 | 1200 | 1600 |
| Input voltage range | DC 10V-14.5DC or 20-29V |
| Output voltage range | AC110~120 or AC220~240 |
| Output frequency | 50H/60Hz+-3Hz |
| Output waveformpure | Pure Sine Wave |
| Optimum efficiency | more than 87% |
| No load current draw(A) | <0.8 | <0.9 | <1 | <1 | <1.2 |
| Cooling Fan | Yes |
| Input over voltage shutdown | 15.5V+/-0.5VDC/30.5V+/-0.5VDC |
| Input low voltage shutdown | 10V+/-0.5VDC/20V+/-0.5VDC |
| Low battery alarming | 10.5V+/-0.3VDC/21V+/-0.5VDC |
| Overload shutdown | Yes |
| Over temperature shutdown | >75C |
| Operating temperature range | -10C~+50C degree centigrade |
| Storage temperature range | -20C~+60C degree centigrade |
|
|
|
|
|
|
| Technical Parameter |
|
|
|
|
|
| Specification | PS1000 | PS1200 | PS1500 | PS2000 | PS2500 |
| Continuous Output Power(W) | 1000 | 1200 | 1500 | 2000 | 2500 |
| Spike Output Power(peak)(W) | 2000 | 2400 | 3000 | 4000 | 5000 |
| Input voltage range | DC 10V-14.5DC or 20-29V |
| Output voltage range | AC110~120 or AC220~240 |
| Output frequency | 50H/60Hz+-3Hz |
| Output waveformpure | Pure Sine Wave |
| Optimum efficiency | more than 87% |
| No load current draw(A) | <1.5 | <1.5 | <1.5 | <1.5 | <1.5 |
| Cooling Fan | Yes |
| Input over voltage shutdown | 15.5V+/-0.5VDC/30.5V+/-0.5VDC |
| Input low voltage shutdown | 10V+/-0.5VDC/20V+/-0.5VDC |
| Low battery alarming | 10.5V+/-0.3VDC/21V+/-0.5VDC |
| Overload shutdown | Yes |
| Over temperature shutdown | >75C |
| Operating temperature range | -10C~+50C degree centigrade |
| Storage temperature range | -20C~+60C degree centigrade |
|
|
|
|
|
|
| Technical Parameter |
|
|
|
|
|
| Specification | PS3000 | PS4000 | PS5000 | PS6000 |
|
| Continuous Output Power(W) | 3000 | 4000 | 5000 | 6000 |
|
| Spike Output Power(peak)(W) | 6000 | 8000 | 10000 | 12000 |
|
| Input voltage range | DC 10V-14.5DC or 20-29V |
| Output voltage range | AC110~120 or AC220~240 |
| Output frequency | 50H/60Hz+-3Hz |
| Output waveformpure | Pure Sine Wave |
| Optimum efficiency | more than 87% |
| No load current draw(A) | <1.5 | <1.5 | <1.5 | <1.5 |
|
| Cooling Fan | Yes |
| Input over voltage shutdown | 15.5V+/-0.5VDC/30.5V+/-0.5VDC |
| Input low voltage shutdown | 10V+/-0.5VDC/20V+/-0.5VDC |
| Low battery alarming | 10.5V+/-0.3VDC/21V+/-0.5VDC |
| Overload shutdown | Yes |
| Over temperature shutdown | >75C |
| Operating temperature range | -10C~+50C degree centigrade |
| Storage temperature range | -20C~+60C degree centigrade |
| Pure Sine Wave Inverter With AC charge (PSC series) |
1. Pure sine wave output(THD<3%)
2.Power ON-OFF switch
3.Thermo control cooling fan
4.Two-color indicator display power and fault status.
5.Protections: short circuit,overload,over/low temperature.
6.Battery voltage, over battery voltage,lack-voltage alarm.
7.Topology: Microprocessor
8.With AC charge
9.Approvals: ROHS/CE
10.1 year warranty. |
| Technical Parameter |
| Specification | PSC1000 | PSC1500 | PSC2000 | PCS2500 | PSC3000 |
| Continuous Output Power(W) | 1000 | 1500 | 2000 | 2500 | 3000 |
| Spike Output Power(peak)(W) | 2000 | 3000 | 4000 | 5000 | 6000 |
| Input voltage range | DC 10V-14.5DC or 20-29V |
| Output voltage range | AC110~120 or AC220~240 |
| Output frequency | 50H/60Hz+-3Hz |
| Output waveformpure | Pure Sine Wave |
| Optimum efficiency | more than 87% |
| No load current draw(A) | <1.5 | <1.5 | <1.5 | <1.5 | <1.5 |
| Cooling Fan | Yes |
| Input over voltage shutdown | 15.5V+/-0.5VDC/30.5V+/-0.5VDC |
| Input low voltage shutdown | 10V+/-0.5VDC/20V+/-0.5VDC |
| Low battery alarming | 10.5V+/-0.3VDC/21V+/-0.5VDC |
| Overload shutdown | Yes |
| Over temperature shutdown | >75C |
| Operating temperature range | -10C~+50C degree centigrade |
| Storage temperature range | -20C~+60C degree centigrade |
Zhejiang Ximeng Electronic Technology Co., Ltd. specialized in designing R&D production and sale. We have Independent import and export rights. The main products are switching power supply, LED driver power supply, AC/DC adapter, Electrical plug&sockets, Indicator lamp, terminal blocks, cable glands and related wiring accessories, Push button switches, and so on. All products are exported by our company YUEQING XIMENG IMP&EXP. Co., Ltd.
Our company is a high-tech company specialized in designing. R&D. Production and sale, the products Switching Power Supply are with the characteristics of the low price, high efficiency, high reliability, long lifetime and so on. Our products are widely used in industrial automation field, indoor and outdoor LED lighting, LED lighting projects, communication, instrumentation, etc. Our Switching Power Supply is the ideal upgraded product to replace traditional controlling transformer. The design of this series of products is in accordance with such international standards as American UL1012, German TUVEN60950, IEC950, UL1950 and EC EMCLVD. Relying on high-quality imported components, advanced production techniques and perfect testing equipment, we create high-quality XIMENG products. XIMENG products sell well in domestic markets and in Europe and Southeast Asia. Our company focuses on innovating science and technology, wining a reputation with quality, and pursuing development with sincerity. We always update our equipment and create new products constantly, striving to follow the core mind of Science and Technology to improve life and supply wide customers with sincerity, high-quality products and highly efficient service. In order to thanks to the long-term support and the cooperation of customers at home and abroad, as well as develop new business field, our company warmly welcomes all the customers to come for instruction and discuss cooperation. Let us develop together and create our prosperous future!
