Pure Sine Wave Inverter UPS

Prod Model:	UPS-1000VA
Markets:	Eastern Europe,Africa,Oceania,Mid East,Eastern Asia
Power:	80%
Certification:	CE,ISO9001
Phase:	Single Phase
Protection:	Short Circuit
Application:	PC
Brand:	Ruikang

Product Description

Product descriptions:
UPS AC automatoc voltage regulator AVR EI transformer inverter LCD digital  display pure sine wave
LCD digital display
CPU control
Automatic  voltage regulator(AVR)
Inverter.while volltage is under 145V,automatically
Transforem to inverter output
Sine wave output ,be suitable for all kind of appliance
Battery over discharge protection
Overload &short circuit protection
Work for long life

Function:
Input :165-275V AC
Output:220±2%(battery supply);190V-246V(electric supply)
Frequency:50/60Hz
Power:500VA/100VA/1500VA/2000VA

Applications:
UPS is used to automatically adjust output voltage of the power supply circuit or power supply equipment
It use as a backup battery to supply the powerto the equipment when it out of power suddenly
It can be widely used in places require stable power supply voltage,such as industrial and mining enterprise,oil,railways,constraction sites,schools,hospitals,telecommunications,hotals,research and other departmentas of computor,precision machine tools,computor tomography(CT),precision instruments,test equipment,elevator lighting,imported equipment and production lines and more

Factory history:
Established from year 1993,with 20years of experience,we have built up the professional teams of R&D,technology,production,supply and marketing with our target of buiding a centennial enterprise and global brand
We are specialiaes in all kinds of power supply products contain automatic voltage regulator/stabilizer,UPS, inverter,step up&down transformer and battery charger with full set of auto production equipment and 300 workers
We also insist on manufacturing electronic component like hardware,circuit board,coil,consent,plug and socket by ourselves to ensure high quality and competitive price for global valued customers

Packing:
Double packing:color box and outer carton
500VA-1500VA:4pcs/ctn
2000VA:2pcs/ctn
3000VA-5000VA:1pc/ctn
1*20Ft can bwe loaded 2900pcs
1*40GP can be loaded 3500pcs

Model		500VA	1000VA	1500VA	2000VA
Capacity		300W	650W	1200W	1500W
Input	Battery Supply Voltage	12V DC	12V DC	24V DC	24V DC
	Electric Supply Voltage	165-275V AC
	Frequency	50/60Hz
Output Voltage	Battery Supply Voltage	220±2%V AC
	Electric Supply Voltage	220±10% V AC
	Frequency	50Hz
	Output Waveform	Pure sine wave
	Real power	60%
Charge	Charge Voltage	15V DC	15V DC	29V DC	29V DC
	Charge Current	6A-8A	10A-15A	12A-18A	14A-20A
	Full Charge Protection	Automatic stop charge when full charge
Transfer	Transfer mode	Power frequency backup type,uninterruptible transform
	Transfer time	Transfer time typical value 6mS
Others	Overload Protection	Overload automatic cut off output
	Short circuit protection	Output short circuit protection
	Low-voltage protection	Warming when battery voltage less than 10.5V,Cut off output  when it less than 10V
	Environment temperature	0-40°C
