Qr540 Coaxial Trunk Cable/Rg540 Coaxial Cable

Name: Qr540 Coaxial Trunk Cable/Rg540 Coaxial Cable
Brand: all-electronics-online.com
SKU: 763008855
Availability: InStock
Rating: 4.6 (123 reviews)

Price:	US $ 0.01/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	DSC-QR540 Messenger
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Commscope Hfc Trunk Coaxial Cable P3.500:	CATV Cable Qr500
Application:	RF Cable
Conductor Material:	BC/CCS/CCA/TC/CU/CCAG
Cover Material:	PVC
Certification:	RoHS
Type:	CATV Cable Qr500
Model:	CATV Cable Qr500

Product Description

QR540 Coaxial Trunk Cable/RG540 Coaxial Cable

Trunk Coaxial Cable QR540 With Messenger

Product specification:

Coaxial Cable 540 Messenger		TYPE	QR540 Messenger
Construction
Item	Material			Diameter(mm)
Center Conductor	Copper Clad Aluminum			3.15
Dielectric	Foam PE			12.0
Outer Shield	Solid Aluminum Tube			0.61thickness
Jacket	PE			15.49
Electrical Charateristics
Impedance(Ω)				75±3
Capacitance(pF/m)				50±3
Velocity of Propagation(%)				87.0
DC Loop Resistance(Ω/km)				5.64
Maximum Pulling Tension(kgf)				136
Return Loss
5-1000MHZ(dB)				≥22

@Frequency(Mhz)	Max Attenuation(dB/100m)
5	0.52
55	1.77
83	2.17
211	3.58
250	3.94
300	4.30
350	4.69
400	5.02
550	5.97
600	6.27
750	7.09
865	7.68
1000	8.27

Packaging: 1) 500m/wooden reel 2)750m/wooden reel 3)1000m/wooden reel

Applications

(1) CATV-community antenna television.

(2) CCTV-closed-circuit television.

(3) DBS-direct broadcasting satellite.

Other Cables:

1) Lan Cable / Network Cable UTP/ FTP /SFTP Cable Cat5e Cat6 Cat3

2) Telephone Cable,Telephone Drop Cable, PTT298 Cable , PTT299 Cable

3) Security Alarm Cable / Fire Alarm Cable

4) Optical Fiber Cable

5) Speaker Cable / Power Cable / Electrical Cable / Multi-Core Cable

6) Siamese CCTV Cable RG59+2C , KX6+2C , RG6+2C

7) Trunk Cable QR750 QR540 QR500 QR412

8) KoaxialKable CT100,CT165, KX6, KX8,17VATC,19VATC,SAT703,SAT602

9) 75 ohm Coaxial Cable RG6 RG59 RG7 RG11

10) 50 ohm Coaxial Cable RG174 RG58 RG8 RG213 RG214 RG223

11) 50ohm Cable LMR195 LMR200 LMR240 LMR300 LMR400 LMR500 LMR600

12) 75 ohm Coaxial Cable 3C-2V, 5C-2V, 4C-FB, 5C-FB

13) 50 ohm Coax Cable 3D-FB,4D-FB,5D-FB,7D-FB,8D-FB,10D-FB

14) Mini Coax Cable: RG591885A,8218 Cable,1.37mm,0.81mm ect

15) Cabo Coaxial RG6 RG59 RG11 QR500 RF4mm

16) Telecom Cable BT3002, PCM Cable, Multi-Core Coax Cable

17) Coaxial Cable Connector(BNC,RCA,Female, Male)

18) Indoor TV Antenna, Outdoor TV Antenna,Satellite Antenna

19) CATV Transimitter, CATV Amplifier,CATV Receiver

Contact information:
24 Hours Available
Name:Wendy Lee
Mobile (waht's app):+86 15958030333
Phone:+86-571-61070066
Fax:+86-571-63763198

Web address:www.dongsheng.com

DSC Located at the city of Lin'an, Hangzhou, Hangzhou Lin'an Dongsheng Cable Co., Ltd. is 28km away from Hangzhou City, covering an area of 30000 square meters, with beautiful landscape and convenient communication facilities.

Since 1991, 24 year cable experience, our rapid development helps us to be the industry leader. Our company has passed ISO9001 quality system certification & UL certification, and had foreign trade license. Our company is on the top with comprehensive strength.

Main products in our company cover LAN Network Cables Cat5e CAT6 Cat3, Coaxial CCTV/CATV Cable RG6 RG59 RG11 RG59-2C QR500 RG58 RG213 LMR400 KX6 19VATC CT100 SAT703 ect. Telephone Cable, Alarm Cable and Cable Accessories

Our motto is "Keeping pace with the time, and going up like the sun", just as our company's name, Dongsheng, suggests. We are looking forward to establishing long term & mutually beneficial business relationship with you.
