Quality 50ohms RF Coaxial Cable (3D-Fb Dual)

Quality 50ohms RF Coaxial Cable (3D-Fb Dual)
Price: Negotiable/Meter
Trade Terms: FOB,CFR,CIF
Min Order: 5000/Meter
Pay Type: L/C,T/T,Western Union
Prod Model: 3D-Fb Dual
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Ottocable: 3D-Fb Dual
Inner Conductor: 1.00CCS/Bc
Insulation: 3.00foam PE
First Shield: 3.10bonded Aluminum Foil
Second Shield: 3.60tc Wire Braid/Al/TCCA
Jacket: 5.00PVC/PE/Lszh
Jacket Color: as Per Request
Impedance: 50ohms
Origin Of Place: Zhejiang, China
Application: RF Cable
Certification: RoHS
Conductor Material: Tc Wire Braid/Al/TCCA
Cover Material: PVC/PE/Lszh
Type: Coaxial
Wire Core Material: Bare Copper/CCS
Model: 3D-Fb Dual
Brand: Ottocable

Product Description




3D-FB


This is a JIS foam coaxial cable with solid inner conductor. It has a good attenuation and shielding effectiveness.As a substitute for RG58 coaxial cable,it has been widely applied to radio transmission,base radio antenna station and other communication systems.

Features
·         50 Ohm data signal transmission;
·         The shielding layer composed of aluminum foil and braiding has a good shielding effectiveness;
·         Excellent performance in high frequency,VSWR stability;
·         Customized cable color , winding and connector, meet your different requirements;
·         RoHS compliant;

Assemblies & Application
These 50 Ohm 3D-FB coaxial cables can be fixed kinds of connectors,such as SMA,N,BNC,TNC connectors.As a substitute for RG58 coaxial cable, these versatile cable assemblies with various lengths have been widely applied to CDMA,GSM radio transmission,base radio antenna station and other communication systems.



Coaxial Cable 3D-FB Dual (Combined with 2 pcs 3D-FB)
Construction
ItemMaterialDiameter(mm)
Inner ConductorBare Copper or Copper Clad Steel1.00
Dielectric Foam PE3.00
First ShieldBoned Aluminum Foil3.20
Second ShieldTinned Copper Braid ---
JacketPVC/PE/LSZH5.40

Electrical CharacteristicsAttenuation @20ºC (dB/100M)
Impedance(Ω)50@100MHz10.4
Velocity of Propagation(%)81.0@350MHz19.5
Return Loss(dB)≥20@900MHz31.8
VSWR(dB)≤1.3@1200MHz37.2
Shielding Effectiveness(dB)≥85@1500MHz41.5
Operating Temperature(ºC)-25 to +70@1800MHz45.6
  @2500MHz54.0



More Ideas
1)  If require conventional construction and materials, please click 3D-FB;
2)  If require lightweight and weldable shield,please click 3D-CCS-TCCA;
3)  If require lightweight and lower price,please click 3D-BC-AL or 3D-CCS-AL;
4)  If require high tensile strength,please click 3D-CCS-AL;
5)  For more 3D-FB assemblies,please click 3D ASSEMBLIES;
6)  Any other requirements or queries, please click CONTACT US.

Company Link:     http://ottoding.en.made-in-china.com/
Otto Cable Technology Co., Ltd. is a Hi-Tech enterprise specializes in researching, manufacturing and selling 50 Ohm & 75 Ohm coaxial cables, cable assemblies and other related products.

After decades of practical experience and technical skills, we have been very professional on these products, which covers:

1). Wireless RF Transmission coaxial cable, 50 Ohms RG MIL-C-17 and JIS Spec coaxial cables, mainly applying to 4G, 3G, GSM, and CDMA telecommunication system, digital microwave communication system, DAS, GPS and other car antenna system.

50 Ohm coaxial cable assemblies/pigtails/jumper cables/pre-made coax cables usually fixed with various connectors, such as N, SMA, SMB, MCX, MMCX, TNC, BNC, UHF...

2). 75 Ohms RG MIL-C-17 Spec coaxial cables, CCTV, CATV-MATV coaxial cable, satellite coaxial cable, video coaxial cable, which are serving for existing and next generation TV network and security monitoring and control systems.

Besides of the standard coaxial cables, customer required cables and value-added services are also available in our company.
