Rechargeable 503035 500mAh Lipo Lithium Li-ion Battery

Name: Rechargeable 503035 500mAh Lipo Lithium Li-ion Battery
Brand: all-electronics-online.com
SKU: 822203595
Availability: InStock
Rating: 4.6 (140 reviews)

Price:	US $ 0.88-1.5/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	502030
Application:	Bluetooth Headset/Bluetooth Speaker
Cycle Life:	500 Times
Warranty:	12months
Weight:	12g
Service:	OEM/ODM
PCM:	Over-Charge,Over-Discharge,Short Circuit etc
PVC:	Added by Customer's Enquirements
Connector:	Customer's Pointed, Melex, Jst etc
Type:	Lithium-Polymer Battery
Usage:	Digital Products
Discharge Rate:	Medium Discharge Rate
Shape:	Square Battery
Rechargeable:	Chargeable
Nominal Voltage:	3.7V
Electrolyte:	Lithium Ion

Product Description

503035 500mAh Lipo lithium li-ion battery
Parameter Table

Item		Rating	Note
3.1 Capacity	Typical	500mAh	Discharge:0.2CmA cut off Voltage:3.0V for cell
3.1 Capacity	Minimum	450mAh	Discharge:0.2CmA cut off Voltage:3.0V for cell
3.2 Nominal Voltage		Average 3.7V	Discharge:0.2CmA cut off Voltage:3.0V for cell
3.3 AC Impedance Resistance		≤240mΩ
3.4 Discharge Cut-off Voltage		3.00V
3.5 Charge Current		100 mA	Standard Charge
3.6 Charge Voltage		4.2V
3.7 Max. Charge Voltage		4.23V
3.8 Storage humidity		< 75%RH	Hygrometer
3.9 Max. Charge Current		500mAh	1.0CmA
3.10 Max. Discharge Current		500mAh	1.0 CmA
3.11 Weight		Approx 12.0g
3.12 Operating Temperature	Charge	0~+45°C
3.12 Operating Temperature	Discharge	-20~+60°C
3.13 Storage Temperature	less than 1 month	-20~+45°C	Recommended storage temperature: 20°C,at the shipment state

Products Picture

Packaging

Advantage
1. Environmental friendly
2. High density of energy
3. Light weight
4. Low self-discharge
5. Low internal resistance
6.Long cycle life, chargeable up to 500 times
7. No memory effect
8.Doesn't contain Mercury, No fire, No explosion, No leakage
FAQ
1. Q:Where can I get the price?
    A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we'll regard your inquiry priority.
2. Q: How can I get a sample to check your quality?
    A: After price confirmation, you can require for samples to check our quality.
3. Q: What about the lead time for mass production?
    A: Honestly, it depends on your order quantity and the season you place the order. We suggested that you start inquiry to months before the date you would like to get the products at your country.
4. Q: What is your terms of payment?
    A: We accept T/T and L/C.

Shenzhen A&S Power Technology Co., Ltd, a OEM rechargeable battery manufacturer in China over 10 years. Specialized in LiFePO4 battery, lithium polymer battery and Li-ion Battery pack. Our products are widely used in popular electronic products, such as Bluetooth Headset, Portable Speakers, consumer products, emergency light, GPS, digital player, solar & wind energy storage, electronic auto and E-bus.

A&S Power has well presence in international fairs each year, such as CEBIT, HK Electronic Fair. We strictly implement the international management standards and have established a complete quality assurance system. So it's no wonder that our products got CE, UL, IEC62133, RoHS certification. We have succeeded in selling our batteries to the international markets of America, Canada, Europe, Africa, middle-east and South Asia. As responsibility and experienced manufacturer, A&S Power is officially recognized by Philips, Mitel. We use "People oriented, Quality first, Keeping improving" as our mission statement, which makes us improve quality, reduce cost and enhance services constantly. We pay more attention to the market change, client needs, safety & environmental protection and take the responsibility of the society. A&S Power dedicates to creating the life stage of employees and supplying lithium batteries welcomed by customers in the world. With passion and faithfulness, we dedicated to establish win-win business and striding forward to create a bright future for your esteemed company.
