| Prod Model: |
TL645 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
70(L)*47(W)*100(H)Mm |
| Number Of Cell: |
3 |
| Approx Weight: |
0.74kg |
| Color: |
Black/ Grey or Other |
| Terminal: |
F1/ T6/ T9 |
| Container: |
ABS |
| Charge (Cycle Use): |
7.2~7.5V |
| Charge (Standby Use): |
6.7~6.9V |
| Designed Life: |
3 Years |
| Warranty: |
1 Years |
| Type: |
Lead-Acid Batteries |
| Usage: |
Electric Tool |
| Nominal Voltage: |
6V |
| Discharge Rate: |
Medium Discharge Rate |
| Shape: |
Square Battery |
| Rechargeable: |
Chargeable |
Product Description
TELONG TL645 (6V4.5ah) Rechargeable Maintenance Free Battery. It has obtained the CE and RoHS authentication of the European Union, UL recognition the USA. The battery is widely used for electric toy,
power tool, alarm system, emergnency light ,electric scale so on.
SPECIFICATION of 6V4.5ah Rechargeable Maintenance Free Battery
| Nominal Voltage | 6V |
| Rated capacity (20 hour rate) | 4.5Ah |
| Dimension | Length | 70mm (2.73 inches) |
| Width | 47mm (1.83 inches) |
| Height | 100mm (3.90 inches) |
| Weight Approx | 0.74Kg(1.63 Ibs) |
FEATURE of 6V4.5ah UPS Battery
1).Absorbent Glass Mat(AGM) technology for efficient gas recombination of up to 99%and
freedom from electrolyte maintenance or water adding.
2).Not restricted for air transport-complies
3).UL-recognized component.
4).Valve Regulated Construction .Can be mounted in any orientation.
5).Computer designed lead, calcium tin alloy grid for high power density.
6).Long service life, float or cyclic applications. Maintenance-free operation.
7).Low self discharge. Long Life Design
8).Wide Operation Temperature Range
9).Available in flame retardant ABS material for the battery case
CHARACTERISTICS of 6V 4.5ah Solar Power Battery
Capacity
25'C (77'C) | 20 hour rate(0.225A ) | 4.5AH |
| 10 hour rate(0.419A ) | 4.19AH |
| 5 hour rate(0.770A ) | 3.85AH |
| 3 hour rate(1.150A ) | 3.45AH |
| 1 hour rate(2.830A ) | 2.83AH |
| Internal Resistance | Full charged Battery at 25 'C(77'F ) | 25 milli-ohm |
| Capacity affected by Temp | 40'C (104F) | 102% |
| 25'C (77'F) | 100% |
| 0'C (32'F) | 85% |
| (-15'C )5'F | 65% |
| Self-Discharge | Capacity after 3 month storage | 91% |
| 25'C (77'F) | Capacity after 6 month storage | 82% |
| Capacity after 12 month storage | 64% |
| Terminal | F1 |
| Charge | Cycle | Initial Charging Current less than 1.35A |
| (Constant Voltage) | Voltage 7.2-7.5 V |
| Float | Voltage 6.7-6.9 V |
APPLICATIONS of 6V 4.5ah Sealed Lead Acid Battery
UPS / Electric Tools / Power tool
Medical equipment /Emergency Lighting
Alarm system / Portable Light / Electronic Scale
Electric Power Supply /DC power Supply
Other standby or primary power supplies.
OTHER INFORMATION of 6V4.5ah Valve Regulated Lead Acid Battery
| 1 | Logo: silk printing |
| 2 | Packaging: in Carton Box Packing in Wooden Pallet
Pcs/ctn: 24pcs/ctn
Ctn size: 381*220*130mm
GW/NW: 17.0kg/16.8kg |
| 3 | Payment terms: T/T(with 30% deposit); L/C at sight |
| 4 | Date of delivery: 15-25days after receipt of the deposit |
| 5 | Loading port: Shenzhen (China) |
| 6 | Sample charge: FREE |
