Rechargeable LiFePO4 Lead Acid Battery Replacement Lithium Battery 12V 20ah and Battery Packs

Rechargeable LiFePO4 Lead Acid Battery Replacement Lithium Battery 12V 20ah and Battery Packs
Price: US $ 30-35/Piece
Min Order: 10/Piece
Pay Type: L/C,T/T,D/P,Paypal
Prod Model: UBFP-12V20Ah
Lead Time: 10 Days
Certificate: Ce, UL, RoHS, IEC, Un38.3
Type: Lithium-Ion Battery Pack
Connection Mode: Series and Parallel
Rated Capacity: 20ah
Standard Voltage: 12V
Usage: Emergency Battery

Product Description

Rechargeable LiFePO4 Lead Acid Battery Replacement lithium battery 12V 20ah and battery packs

Specification :

Battery Pack Characteristics
ModelUBFP-12V-20Ah (4S5P)
Capacity(0.2C5A)20Ah
Nominal Voltage12.8V
Max. Charge Voltage14.6V
Discharge Cut-off Voltage10V (recommended)
Working Voltage Scope10V~14.6V
Max. Charge Current10A
Continuous Discharge current20A
Max.Discharge current60A 3Sec
PCM control Discharge current20A (continuous)
Weight (Approx.)2.8Kgs
Battery Dimensions151x95x99mm(H*W*L)
Impedance
(Max, at 1000Hz)
Single Cell≤25 mΩ
Cycle Life(80DOD%)>2000 Times
Self-discharge Rate≤3%(month)
Charge Method
(CC/CV)
Standard50A×4hrs
Quick10A×2hrs
Operating Temperature

 Charge0ºC~45ºC;32oF~113oF
Discharge-20ºC~60ºC;-4oF~149oF



Application



1. Large-scale electric vehicles: electric bus, electric carE-Tour Car

2. Light electric car: e-bike, electric scooter,e-motor, electric golf car, forklift, cleanness car, electric wheelchairs

3. E-tool: electric drill, electric saw, lawn mower and so on

4. Remote control cars, boat, aircraft, toys

5. Solar and wind power generation energy storage devices

6. Small medical equipment and portable equipment


Battery Features


1,Safety: The iron-lithium battery is more safe and reliable than the lead acid one. It does not explode or burn when bump, heavy stress, needle pricking, short circuit, overcharge and overheat.

 2Environmental Protection: Accredited with RoHS, without any hazardous and noxious substances.

 3, Small in Volume and Light in Weight: The iron-lithium battery is about 1/2 the volume and 1/3 the weight of the lead-acid.

 4, Strong Power: Able to discharge with 20C at 65. C max.

 5, Steady Performance: High power output: 1C, continuous: 3C pulse for normal cells and 20 C for special design. Low self-discharge rate, less than 3% monthly.

6, Long Cycle Life: Over 2000 cycles with capacity staying at 80% min.

 7, Lower Average Price per Year: The average price per year is 100 Yuan RMB less than the lead-acid battery for 5 years.

 8, No Memory Effect: Always ready for charge and use, with no need to charge after a full discharge.

 9, Wide Temperature Range: Available for use when the temperature ranges from -20° C to 70° C

10, Intelligent Charge System: Voltage of each cell can be detected. Each cell can be protected against overcharge, overvoltage, short circuit and overheat, and so that battery can be charged balance. The capacity of readout power volume: Each battery has 5LED lights to readout the capacity of the battery









Introduction

Shenzhen Ubetter Co., Ltd, founded in 2013, has become a comprehensive battery manufacturer with the combination of R&D, manufacturing, marketing and service.

Shenzhen Ubetter, The Leader of Li-ion polymer batteries manufacturer, located in Shenzhen city, is specialized in Power battery series(such as electric-bikes, electric scooter and electric cars, etc), Storage battery, High-rate discharge Lithium ion battery(10C-60C high-rate discharge series such as air modeling and power tool etc), ). High Temperature Li-ion battery(up to 85° ), Low Temperature Polymer Li-ion battery(up to -40° ), Ultra-thin battery(up to 0.43mm). Ubetter has succeeded to solve the power battery core technologies problem: High Consistency and Excellent Safety Performance. Products' performance is leading in domestics market and in path with international standards. Products are widely employed in digital products series(such as MP3, UPS, etc. ), notebook PC series, 18650 series, and sales over 100 countries worldwide.

With over 4000 square meters dust-free workshop, 200 employees, automatic production lines and modernized equipments, Ubetter is offering reliable quality, efficient delivery and competitive price, by which we have gained global reputation. We are qualified for ISO9001, UL, CE, RoHS, IEC, UN38.3, MSDS, patent approves and National Hi-TECH Enterprise certification.

Our advantages

Shenzhen Ubetter Technology Co., Ltd. is a famous enterprise in the line of China's new energy business, mainly producing environmentally friendly power battery for electric vehicles, integrating the research and development, producing and selling of Lithium-ion Battery, wind and solar Energy Storage Battery as well as various kinds of batteries. Bearing with the spirit of pragmatism and innovation, we have been endeavoring to produce products with best quality for all walks of life by people-oriented management and high efficiency production line. Our R&D department has mustered skilled persons with over ten years' experience in battery research and developing, playing an leading role in the field of R&D of more and more series of batteries. Meanwhile we have cooperated with many big battery enterprises for many years and have numerous connections in this line of business. We have abundant battery resources with guaranteed quality. Shenzhen Ubetter Technology Co., Ltd. is located in the beautiful Dapeng bay with charming and beautiful scenery, excellent geographical location and convenient transportation.
