Red PVC Jacket Aluminum Conductor Electric Wire

Prod Model:	BLV
Type:	Insulated
Conductor Type:	Stranded
Application:	Underground
Conductor Material:	Aluminum
Insulation Material:	PVC
Certification:	RoHS
Brand:	Sansen

Product Description

Synthetic data of 300/500V BLV model PVC insulated round cable with aluminum core and PVC sheath

Nominal cross section of conductor mm2	Minimum number of single line in the stranded conductor	Rated value of insulator thickness mm	Rated value of sheath thickness mm	Upper value of average overall diameter mm	Maximum resistance of aluminium conductor Ω/km	Minimum insulation resistance MΩ.km
2.5 4 6 10	1 1 1 7	0.8 0.8 0.8 1.0	0.8 0.9 0.9 0.9	5.7 6.5 7.1 8.8	12.1 7.41 4.61 3.08	0.010 0.0085 0.0070 0.0065

FAQ

Q1. What kind of products can your company supply?
 A: We specialize in supplying network cable, coaxial cable,power cable ,control cable , telephone cable, speaker cable and ect.

Q2. What's your MOQ?
A: The MOQ of long meter cable is 50 km, or we can negociate.

Q3. What's your delivery time?
A: Our delivery time is about 15-20 days after comfriming the deposite, it is based on the quantity of the order.

Q4. What are your payment terms?
A: Normally, we accept T/T in advance, as for other payment term, we can negociate with you.

Q5. What's your trade term ?
A: We can accept FOB, CIF, EXW term.

Q6. What's your conventional packing ?
A: 100m/plastic or wooden drum, 305m/wooden drum or color box. However, we can produce according your demand.

Q7. Can your factory customize cables based on clients' samples or data sheet ?
 A: Yes, we can.

Q8. Can you offer me a free sample?
A: Yes,we do,that is a start of business-i think. And you will only pay the cost of delivery,
which we will return it to you when you put the order.
