Refrigeration Spares Parts of Cbb65 Sh Capacitor for Air Conditioner
| Price: |
US $ 1.22/Piece |
| Min Order: |
1000/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
CBB65 |
| Model Number: |
Cbb65 |
| Size / Dimension: |
50*110 |
| Rated Voltage: |
450V |
| Pins: |
4+4+4/2+3+4 |
| Operating Temperature: |
25/70/21 |
| Certificate: |
Ce RoHS |
| Type: |
Polystyrene-film-capacitors |
| Application: |
Air Conditioner |
| Package Type: |
Surface Mount |
| Manufacturing Material: |
Plastic Case and Capacitor Mpp Film |
| Electrolyte: |
Film Capacitor |
Product Description
The design of Refrigeration Spares Parts of CBB65 SH Capacitor for Air Conditioner
 | Voltage:370/450V
Pins:2+2/2+4
4+4+4/2+3+4 |
 | AC RUNNING CAPACITOR |
 | Air Conditioner Capacitor |
Refrigeration Spares Parts of CBB65 SH Capacitor for Air ConditionerThe company's CBB65 series air conditioner compressor capacitor, quality reliable, large inventory, complete model. Due to the introduction of foreign advanced equipment and technology, product stability is excellent, impact resistance. In addition products used in the Nordic material of the metal film, to ensure that the capacity of the capacitor overload, loss of small, high insulation resistance. Through the process of the production process of strict control to make the product of the rated service life long excellent self-healing performance. Built in filling material is a safe and reliable filling of wax. Our CBB65 series air conditioning capacitor built-in explosion-proof block and shell aluminum shell seal, so as to achieve the best effect of explosion-proof. CBB65 series air conditioning capacitor is widely used, used in refrigerators, air conditioners and so on.
The parameters of Refrigeration Spares Parts of CBB65 SH Capacitor for Air Conditioner | Capacity range | 5uf~150uf |
| Capacity deviation | +/- 5%or according to customer requirements |
| Rated voltage | 125V~500VAC,50/60Hz |
| Use temperature range | -25ºC~+70ºC |
| Loss tangent | ºC.50/60Hz) |
| Lead to terminal resistance | AC >= 1.75Un 5S no breakdown |
| Resistance between the lead and the housing | AC >= 2000V 10S no breakdown |
| Insulation resistance | Rj . C >= 3000M Ω . μ F. Rj >= 1000M Ω |
| Execution standard | GB/T3667.1-2005 IEC60252-1:2001 |
The Size of Refrigeration Spares Parts of CBB65 SH Capacitor for Air Conditioner | CBB65 Size List |
| Item | Capacity(μF) | Size(mm) |
CBB65,4+4+4/
2+3+4 | Capacity(μF) | Size(mm) |
CBB65,4+4/
2+4
| 5μF | 40*60 | 30+5 | 50*100 |
| 7.5μF | 40*60 | 35+5 | 50*100 |
| 10μF | 40*60 | 40+5 | 50*110 |
| 15μF | 40*70 | 45+5 | 50*125 |
| 20μF | 40*75 | 50+5 | 50*125 |
| 25μF | 45*75 | 50+5 | 50*125 |
| 30μF | 50*85 | 60+5 | 50*130 |
| 35μF | 50*85 | 65+5 | 50*130 |
| 40μF | 50*85 | 40+6 | 50*110 |
| 45μF | 50*100 | 45+6 | 50*125 |
| 50μF | 50*100 | 50+6 | 50*125 |
| 55μF | 50*100 | 55+6 | 50*125 |
| 60μF | 50*110 | 60+6 | 50*125 |
| 80μF | 50*125 | 65+6 | 50*130 |
Zhejiang Huaxi Electronics Co., Ltd is located at the foot of national key place of interest Yandang Mountain and abuts on "China Electric Capital"Liushi, Wenzhou. It was founded in 1997 with a floor area of 4, 003 sq. M, and building area of 5, 600 sq. M. At present, it owns more than 100 staff including 16 engineers.
The Company mainly produces(WENHAN, HX brand) kinds of temperature controller, overheat temperature protectors, temperature displays and gas temperature control valves, which are wideyl applied in electric water heater, electric oven, washing machine, plastic machinery, west cabinet equipment, fuel gas oven, gas air-condition, Turkey cooker, boiler pump, central air-condition heating, ventilation system and such support control products.
The companys is development, production of metallized film capacitors. It is equipped with advanced production equipment and detection instruments. The products are of stable and reliable quality and widely used in fields such as communication, household appliances, power supply, green lighting, commputer, industrial control, electric tool, auto-eletctonics, etc.
Since the foundation of the company, we have always insisted on the principle of paying equal attention to talents and products; Absorbing experienced engineers and professional managing personnel. Basing on strict management, high techonlogy, advanced mechanical facilities, perfect test technique, it can provide the user whit high quality products and good fater-sales service. The main products have been certified to CSA, VED, CQC and CE. The quality control system has been wholly carried out in conformity with ISO. The products mand by our company are used with those of famous domestic manufacturers. The company has become the cooperation partner of foreign famous brand OEM. The products are well sold all over China and also exported abroad, selling well around China and exported oversas.
