Replacement 12V 35ah Sealed Lead Acid Battery Solar Light Battery

Name: Replacement 12V 35ah Sealed Lead Acid Battery Solar Light Battery
Brand: all-electronics-online.com
SKU: 803031485
Availability: InStock
Rating: 4.6 (85 reviews)

Price:	US $ 110-120/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,D/P,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	UBT-26650-12V-35Ah
Lead Time:	7-8 Days
Certificate:	Ce, UL, RoHS, IEC, Un38.3
Type:	Lithium-Ion Battery Pack
Connection Mode:	Series and Parallel
Rated Capacity:	35ah
Usage:	Emergency Battery

Product Description

Replacement 12V 35Ah Sealed Lead Acid Battery Solar Light Battery

Specifications

Name	sealed lead acid Battery 35Ah 12V
Part number	FM12350
Nominal Voltage	12V
Dimension(mm)	Length	Width	Height	Total Height
	195+/-2	130+/-2	164+/-2	178+/-2
Approx. Weight	11.2kg
container material	ABS
Rated capacity	20hr,1.8V	10hr,1.8V	5hr,1.75V	3hr,1.75V	1hr,1.67V
	35Ah/1.75A	32.6Ah/3.26A	2.98Ah/5.95A	26.8Ah/8.93A	22Ah/22A
Max discharge current	525A(5s)
Internal resistance	Approx. 11mΩ
Operating temperature range	Discharge	Charge		Storage
	-15°C~50°C	0°C~40°C		-15°C~50°C
Nominal operating temperature	25°C±3°C
Cyclic charging voltage	Initial charging current less than 10.5A voltage 14.4V~15V at 25°C temp.coefficient -30mv/°C
Standby use	No limit on Initial charging current voltage 13.5V~13.8V at 25°C temp.coefficint-20mv/°C
Capacity affected by temperature	40°C	25°C		0°C
	103%	100%		86%

Features:
1)sealed and maintenance free operation
2)Non-spillable construction design
3)ABS containers and covers optional
4)safty valve installation of explosion pro
5)high quality and high reliability
6)exceptional deep discharge recovery per
7)low shelf discharge characteristics
8)flexible design for multiple installation

Application:

      Telephone switchboard, electric equipments, medical equipments, and instruments and meters
      Computer, uninterrupted power source (UPS battery)
      Power transmission and transformer station, switch control, and accident lighting
      EPS, safety device, and alarm systems
      Photovoltaic solar power storage system, wind energy storage system, other renewable energy system
      Automatic office system
      Radio communication system
      Emergency lighting
      Portable electric appliances and mining system
      Traffic and navigation signal lamp
      Generator, Scooter, Marine equipment

Notice:
1). Don't near the hot source and don't under the sunshine.
2). Don't charge in the sealed container or space.
3). No short circuit. It should be addition charge if you don't use, and single charge per three months, to avoid irreversible sulfating. The battery should be changed when the battery jar broken or the electrolyte omitted, to avoid acid corrosion.
4). Don't store in the space of acid gas.
5). You should be careful and regular check when use the battery. To avoid the Koyosonic battery don't work. You should change the battery if the capacity is not full or has been damage, especially after one year using.
6). Don't put the battery in the fire, or it will explode.
7). Please use cotton cloth to clean, if the battery is broken down and leak electrolyte. Please wash your skin when touch the electrolyte.
8). Don't clean the battery by using the organic solution. (e.g. petrol)
