RG11 Tri-Shield Cable

Name: RG11 Tri-Shield Cable
Brand: all-electronics-online.com
SKU: 620129292
Availability: InStock
Rating: 5 (100 reviews)

Price:	Negotiable/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10000/Meter
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	rg11
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application:	Coaxial Cable
Conductor Material:	BC/CCS/CCA/TC/CU/CCAG
Certification:	RoHS
Cover Material:	PVC,PE,Lszh
Type:	Rg11

Product Description

Standard Construction:
Inner conductor: 14AWG (0.064in, 1.63mm) BC/CCS;
Dielectric: 7.11mm Foam PE
1st Shield: Aluminum Foil
2ND Shield: Aluminum braid 6*16*0.16*60%
3rd Shield: Aluminum Foil
Jacket: 10.16mm PVC, PE, LSZH

Electrical Characteristics:
Nominal Impedance: 75Ω +/33
Nominal Velocity of propagation: 85%
Capacitance(pF/m): 53+/3

Packing: 305m/wooden reel/carton
305m/plastic spool/pull box
100m/reel, 4reels/carton
500m/wooden reel/carton

The specification as according to your requirments.

Hangzhou Risun Cable Co., Ltd. Specializes in manufacturing high quality Network-Cable, Telephone wire, and coaxial cable from China. Our company is located at west suburb of Hangzhou, providing convenient access to Shanghai.

Our main products are UTP/FTP Cat5e, CAT6, Telephone Cable, Coaxial Cable, Alarm cable, Patch cord etc. We implement a mature quality control system, ensure that all of our products are certified CE, which certifies that a product has met European Union health, safety, and environmental requirements, and RoHS, ISO9001. In addition, we also supply OEM service to our international clients.

We welcome your visiting to our company. And hope we can be your faithful cable supplier in China and cooperate with you in a long term. If you are interested in our products, please contact us through E-mail, fax or telephone. We will certainly pay close attention to your inquiry and reply you in time.
