RG214 Coaxial Cable

RG214 Coaxial Cable
Price: Negotiable
Trade Terms: by Sea or Air
Min Order: 10/Roll
Prod Model: RG214
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Conductor Material: Copper
Application: Local Communication Cable
Type: Rg214

Product Description

Rg214 Coaxial cable

1. Specifications:
1) 7X0.75mmTC+7.25mmSolidPE+96%TC Braiding +98%TCBraiding +10.8mm PVC (or PE)
2) Customers' specifications are welcomed

2. Characteristics:
Impedance: 50+/-2 Ohm
Velocity of Propagation: 66%
Capacitance: 100pF/m
Attenuation: [@68 F. (20 C) ] dB/100meters
50MHz: 4.50dB 500MHz: 16.30dB
100MHz: 6.70dB 600MHz: 18.60dB
200MHz: 9.80dB 800MHz: 23.00dB
400MHz: 14.70dB 1000MHz: 25.00dB
3. Packing:
1) Packing lengths: 100m/roll, 200m/roll, 305m/roll, 100 yards/roll, 200 yards/roll
2) Inner packing: Wooden drum, plastic drum, paper drum
3) Outer packing: Carton box, pull out box
4) Other packing available according to customer
Zhuhai Surelink Communication Cable Co., Ltd. is a professional manufacturer in producing communication data cables, patch cord, drop wire, telephone cable, alarm cable, coaxial cable, electric cable, telecommunication cable, optical fiber cable, other cables as well as telecom accessories for sixteen years. Our company owns a total investment of USD3, 000, 000 and occupies an area of 20, 000 square meters. Our annual output is more than 600, 000 boxes. We introduced advanced technical facilities and automatic cable inspection system with model of MEAKPA-HF300 from Germany. All our products comply with the standards of ISO/IEC 11801 & TIA/EIA 568B, GB, YD, JIS, DIN and CCITT. Every procedure is inspected and controlled automatically by procedure computers and laser-verify in the procession of production. We stick to the idea of " QUALITY IS EVERYTHING, EVERTHING FOR CLIENT" To ensure high quality. After sixteen years' development, we have greatly enlarged our business scale. Our products have been sold to East Europe, West Europe, Russia, Middle and South America, Africa, North American, the Middle East and Asia with export percentage reaching 85%. We sincerely look forward to establishing business relationship with all reputable buyers from all over the world and create a splendid future in business. If you have any inquiries about our products, please do not hesitate to contact us.
