RG223 Coaxial Cable

RG223 Coaxial Cable
Price: Negotiable
Trade Terms: by Sea or Air
Min Order: 10/Roll
Prod Model: RG223
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Conductor Material: Copper
Application: Local Communication Cable
Type: Rg223

Product Description

RG223, Coaxial cable

Reference standard: MIL-C-17G Black

Type of coaxial cable: RG 223, RoHS compliance
Main Electrical properties:
Characteristic impedance   50±2Ohm
Rated capacitance
Velocity   66%
Operating frequency   100~11000MHz
Attenuation at typical frequencies:dB/ m
100MHz 400mhz 1000mhz 3000mhz 5000mhz 11000mhz
0.131 0.269 0.440 0.814 1.099 1.775
VSWR 100~1000MHz    1.2Max.
Mechanical Construction:
Inner conductor: SCT   0.90±0.02mm
Dielectric:PE PE 2.95±0.05mm
Outer conductor:SCT   3.95±0.05mm
Jacket Black :PVC PVC 5.30±0.05mm
SCT Silver clad copper wire, PE--Low density polyethylene.
Engineering data:
Minimum bending radius   25mm
Operating temperature   -40~+80°C
Reel Length   305m
Jacket marking   SURELINK RG223 XXXM
