Rg59+2 Core Power Cable

Name: Rg59+2 Core Power Cable
Brand: all-electronics-online.com
SKU: 620129862
Availability: InStock
Rating: 4.6 (133 reviews)

Price:	US $ 0.1-0.5/Meter
Trade Terms:	FOB,CFR,CIF
Min Order:	10000/Meter
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	RG59+2 core power cable
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Power Cable:	2*18AWG Copper
Application:	LAN Cable
Conductor Material:	BC/CCS/CCA/TC/CU/CCAG
Cover Material:	PVC
Certification:	ETL
Type:	Combo Cable
Model:	Combo Cable
Brand:	OEM

Product Description

Risun Cable is specialized in producing Lan cable, Network cable: UTP Cat5e, UTP Cat6, FTP Cat5e, FTP Cat6, Telephone Cable, Alarm Cable and Coaxial Cables.

1. All of products we offer are top quality and competitive price;
2. If there is no special explanation, all of our Brand are RISUN or OEM;
3. Payment: We accept T/T and L/C;
4. Packing: 100m/roll, 200m/roll, 300m/roll, PE film/wooden reel.

Mainly application
1. CATV-community antenna television
2. CCTV-closed-circuit television
3. DBS-direct broadcasting satellite etc

Model	RG-59 Coaxial Cable
Conductor Material	Bare Copper,CCS
Conductor Diameter(mm)	0.81
Insulation OD (mm)	3.66±0.03
Insulation Material	Foam PE
Shield	AL Foil
AL Foil	Bonded/Unbonded AL Foil
Braid	0.10, 0.12, 0.13, 0.14, 0.15 and 0.16mm
Braiding Net	32, 48, 64, 72,80, 96, 120, 128 and 144 and more available.
Braiding Net	Coverage:30-97%
Rated temperature	-40 °C - +70 °C
PVC Jacket	6.1±0.2
PVC Color	Optional
Electrical Characteristic	Sparker test: 4000VAC
	Capacitance: 54pF/m
	Impedance: 75Ohm
	Velocity of Propagation: 83%
	Return Loss: 20dB min(5-2300Mhz)

Hangzhou Risun Cable Co., Ltd. Specializes in manufacturing high quality Network-Cable, Telephone wire, and coaxial cable from China. Our company is located at west suburb of Hangzhou, providing convenient access to Shanghai.

Our main products are UTP/FTP Cat5e, CAT6, Telephone Cable, Coaxial Cable, Alarm cable, Patch cord etc. We implement a mature quality control system, ensure that all of our products are certified CE, which certifies that a product has met European Union health, safety, and environmental requirements, and RoHS, ISO9001. In addition, we also supply OEM service to our international clients.

We welcome your visiting to our company. And hope we can be your faithful cable supplier in China and cooperate with you in a long term. If you are interested in our products, please contact us through E-mail, fax or telephone. We will certainly pay close attention to your inquiry and reply you in time.
