Rg59 Coaxial Cable with Power Cable for CCTV / Security System

Name: Rg59 Coaxial Cable with Power Cable for CCTV / Security System
Brand: all-electronics-online.com
SKU: 664951522
Availability: InStock
Rating: 4.7 (120 reviews)

Price:	US $ 30/Piece
Trade Terms:	FOB,FCA,EXW
Min Order:	10/Piece
Pay Type:	L/C,T/T,Money Gram,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	RG59 with power
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Conductor:	0.81mm Copper
Insulation:	Foam PE or Solid PE
Jacket:	White or Black PVC
Application:	Coaxial Cable
Conductor Material:	Copper
Cover Material:	PVC
Certification:	VDE
Type:	Coaxial Cable Rg59
Model:	Rg59 with Power

Product Description

RG59 siamese cable

Specifications:
BC: Bare Copper TC: Tinned Copper
CCS: Copper Clad Steel
CCA: Copper Clad Aluminium C: Cores
1)RG59+2C
RG59: 0.81mm CCS/BC Conductor +3.65mm Solid/Foam PE+BC/TC Braiding +6.1mm PVC Jacket
2C/18AWG power cable: 2C*24*0.20mm BC Conductor + 2.17mm PVC Insulation + 0.63mm PVC Jacket
2) Customers' specifications are wellcomed.

Note:
1) Center conductor: TC, BC and CCS available, CCA;
2) Al-foil: Non-bonded Al-foil, bonded Al-foil, double bonded Al-foil, and double non-bonded Al-foil and Messenger are available;
3) Braiding wire: AL, BC and TC available;
4) Braiding wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15, 0.16mm available;
5) Braiding net: 32, 48, 64, 72, 80, 96, 120, 128, 144 and more available;
6) Braiding coverage: Between 30- 97% available;
7) PVC jacket of Flame retardant, UV, or UL available.

Application:
For audio and power transmission
Power Cable:
1) VDE/KEMA Flexible Cord
2) Light Duty PVC Jacket Flexible Cord
3) Ordinary Duty PVC Jacket Flexible Cord
4) Wire For Internal Wiring Of Equipment
