Rubber OFC Soft Copper Conductor Electric Welding Wire Cable 50mm2

Name: Rubber OFC Soft Copper Conductor Electric Welding Wire Cable 50mm2
Brand: all-electronics-online.com
SKU: 731823182
Availability: InStock
Rating: 4.9 (22 reviews)

Price:	Negotiable/Meter
Min Order:	500/Meter
Pay Type:	L/C,T/T,D/P,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	YH
Standard:	GB/T5031
Type:	Insulated
Conductor Type:	Stranded
Application:	Heating
Conductor Material:	Copper
Insulation Material:	Rubber
Certification:	ISO9001
Brand:	Hongda

Product Description

Rubber ofc soft copper conductor electric welding wire cable 50mm2

Construction

Conductor:

Plain annealed copper wire class 6 / K

Separator:Polyester film isolating layer

Jacket:Ethylene propylene diene Monomer Rubber(EPDM)

Chlorinated polyethylene rubber(CPE)

Standard:IEC 60245

Technical properties:

Rate voltage:450/750V

Working temperaure:-50ºC-+90ºC

Sheath color:Black or red

Feature:

Great Flexibility
Abrasion resistance
Good color retention
Heat oil retardent
Less heat build up
Fire retardant
Weather Resistant
Ozone Resistant
Safety Colored

Application:

Welding cable can be used as entertainment or stage lighting cables for movie theatres, lighting and sound systems, and communication vans. Other possible uses for welding cable include battery cables for cars, inverter cables, and as a cheaper alternative to pendant/reeling cable on hoists and cranes. For example, many solar power installations use welding cable extensively to connect solar panels, battery banks, and converters.

specification:

nal section area (mm2)	Max. diameter of wire (mm)	Coated layer thickness (mm)	Sheath thickness in double coated layers(mm)	Average outer diameter (mm)		Max. resistance at 20ºC (Ω/km)
nal section area (mm2)	Max. diameter of wire (mm)	Coated layer thickness (mm)	Sheath thickness in double coated layers(mm)	Min.	Max.	Tin coated wire	Copper wire
16	0.21	2.0	1.3	9.2	11.5	1.190	1.160
25	0.21	2.0	1.3	10.5	13.0	0.780	0.758
35	0.21	2.0	1.3	11.5	14.5	0.552	0.536
50	0.21	2.2	1.5	13.5	17.0	0.390	0.379
70	0.21	2.4	1.6	15.5	19.5	0.276	0.268
95	0.21	2.6	1.7	18.0	22.0	0.204	0.198

Packaging:

Small cross section cable:100M/Roll then packaged on pallet

Big cross section cable:500M or 1000M packaged on wooden drum

*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!

Shipping:

Port: Tianjin, or other ports as per your requirements.
Sea freight: FOB/C&F/CIF quotation are all available.
*For some countries such as Africa countries, middle east countries, our sea freight quotation is much cheaper than clients get from local shipping agency.
