SAA Portable Distribution Board DTS003

Prod Model:	DTS003
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimension:	Customized
Large Size:	Dtl Series - 420mm X 420mm X 600mm
Medium Size:	Dtm Series - 420mm X 420mm X 600mm
Small Size:	Dts Series - 390mm X 250mm X 270mm
Material:	UV Material
Handle Design:	Easy Carry
Colour:	Orange & Black
Installation:	Plug and Socket with Different Standards
Standards:	IEC
Picture:	Reference
Type:	Power
Structure:	Fixed Board
Size:	All
Shell Material:	PC
Brand:	Metworld

Product Description

Quick Details

Place of Origin:	Zhejiang, China (Mainland)	Brand Name:	Metworld	Model Number:	DTS003
IP Rating:	IP66	Color:	Orange &black	Type:	portable power distribution box
Material:	PE	Feature::	Anti-UV	custom-made:	100%
External Size:	380X250X260mm(H,W,D)	Package:	customer's requirement	Application:	Industrial
Web:	www.nadway,com OR www.cndutian.cn

Descriptipn:

Dimension: 380*250*260mm(H, W, D)

Side A
Enclosure complete with MCB(RCD)
20amp circuit breaker
1.8M leads
16A plug(IP67 waterproof)


SIDE B
6*16A outlets
SIDE C
1*32A 5P IEC SOCKET AND MCB(RCBO)

1.the product is made of a plastic waterproof box,6*15A waterproof sockets,  1* 20A RCBO ,2M 3*2.5 mm screened lead ,and  1*15A waterproof plug.The product are mainly used for equipment of machinery in industry and the mine's power accomodation,palying in role of portable power connection.

2.the plug and the socket 's waterproof rating is IP66,the voltage is 250V,the frequency is 50Hz.However,the RCBO's voltage is 230-415V,the current is 30mA and the Breaking Capacity is 6kA.

3.the components of the product are certified by SAA in Australia.

4.maximum size of the dimension is 450*260*200mm

5.Each product is packed in a box.
