Sc/ PC to SC/PC Mm Om3 Fiber Optic Patch Cord (OM3 SC/PC)
| Price: |
US $ 1-1.5/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
500/Piece |
| Pay Type: |
L/C,T/T,D/P,Paypal,Western Union |
| Prod Model: |
SC/PC MM OM3 Fiber Optic Patch Cord |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Length: |
0.9m, 3m, Can Be Customized |
| Connector: |
SC/PC to SC/PC |
| Applications: |
FTTX, CATV, Cabling System, ODF etc. |
| Keyword: |
Mm Om3 SC/PC Patch Cord |
| Model No: |
Om3 SC/PC Patch Cord |
| Delivery: |
About 7 Days |
| Fiber: |
Om3 |
| Application: |
Telecommunication |
| Connection Structure: |
FC-FC |
| Certification: |
CE |
| Brand: |
Daytai |
| Core: |
Customzed |
| Sheath Material: |
PVC or Lszh |
| Type: |
Sm/Mm/Om3 |
Product Description
SC/ PC to SC/PC MM OM3 Fiber Optic Patch Cord
OM3 Fiber Optic Patch Cord Description:
OM3 Fiber Optic Patch Cord , SC/PC to SC/PC connector , MM,OM3(150), single core, OD: 3.0MM,PVC or LSZH Jacket is optional,Length:3M*2 (The length of other requirements can be provide).
OM3 Fiber Optic Patch Cord Features:
1.Insertion Loss: APC<0.3dB .
PC<0.2Db.
UPC<0.15dB.
2.Return Loss: SM: PC>45dB.
UPC>50dB.
APC>60dB.
MM: >35dB.
3.Repeatability: ≤ 0.1dB.
4.Exchange: ≤0.2dB.
5.Push-pull Performance:≥1000 Cycle.
6.Operation Temperature: -40~+80°C.
OM3 Fiber Optic Patch Cord Specification:
1.Connector: SC/PC to SC/PC
2.Jacket:Pvc or LSZH
3.Length:3m
4.Packing:1 pc/opp bag, 100 pcs into one carton
5.CE,UL,ROHS standard
6.MOQ:100 PCS
7.OEM service
8.Sample is available
9.Delivery time:7~10 days, correct time according to your quantity
10.Payment terms:T/T,L/C,OR Western union
OM3 Fiber Optic Patch Cord Application:
1.Long Distance Optical Communication.
2.Optical Testing System.
3.LAN and MAN.
4.CATV System.
5.Digital Communication System.
ReliabilityText Condition- OM3 Fiber Optic Patch Cord :
Item |
Text Condition |
Text Value |
Optical |
Insertion Loss |
1.3um LED Laser |
≤0.2dB |
Return Loss |
1.3um LED Laser |
≥50dB |
Mechanized |
Exchange |
Interchangeable Random |
<0.2dB |
Vibration |
5~2000Hz,1.5mm Amplitude |
<0.1dB |
Push-pull |
>1000 Cycle |
<0.1dB |
Environments |
High Temperature Storage |
+85°C For 100h |
<0.2dB |
Low Temperature Storage |
-40°C For 100h |
<0.2dB |
Temperature Storage |
-40°C~+85°C, 50 Cycles |
<0.2dB |
Relative Humility |
+25°C~+65°C, 93%R.H, For 100h |
<0.2dB |
*The variation of insertion loss after test.
