| Prod Model: |
DF-FOA123 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Polishing: |
PC/Upc/APC |
| Cable Diameter: |
2.0*3.0mm Drop Cable |
| Insertion Loss: |
0.3 dB |
| Return Loss: |
-45 dB |
| Connection Durability: |
1000 Times |
| Tensile Strength: |
>50n |
| Cable Jacket: |
Lzsh, PVC |
| Connection Structure: |
Sc FC LC St MPO MTRJ |
| Allowed Tensile Strength: |
1000n<10000n |
| Sheath Material: |
PVC |
| Transmission Medium: |
Single-Mode |
| Structure: |
SC |
| Number Of Cores: |
Single-Core |
| Ferrule Endface: |
PC(',UPC) |
| Application: |
Communication |
Product Description
SC UPC Simplex Single Mode Fiber Optic Connector
Specifications:
Fiber optic attenuator
1)High attenuation precision
2)Good environmental stability
3)3 years' gold supplier and 7 years' factory experience
Application:
1. CATV
2. Active device termination
3. Telecommunication networks
4. Metro
5. Local Area Networks (LANs)
6. Data processing networks
7. Test equipment
8. Premise installation
9. Wide Area Networks(WANs)
Features:
*Low insertion loss and back reflection loss
*Ferrule end surface predomed
*Precision anti-rotation key and corrosion resistant body
*UL-rated plastic housing
*Boots in a variety of colors
*Telcordia style boots
*Free-floating ceramic ferrule
Standards
All components and final producs are designed and tested to conform the requirement of IEC 60874-7, CECC 86115-801, Bellcore/Telcordia GR-326, EIA/TIA 604-3A, EIA/TIA 568, ISO/IEC 11801, Belcore/Telcordia GR-409-CORE, IEC 793, IEC 794-1-E1, IEC 794-1-E3, UL 1666/901 and EIA/TIA 455
Availability
1. The connector can be supplied as a pre-assembled one-piece connector or as connector kit.
2. Clips are available for duplex connectors
3. Housing kits without ferrule are available.
Parameter:
| | Singemode(UPC) | Singemode(APC) | Multimode |
| Insertion loss | ≤ 0.2db | ≤ 0.2db | ≤ 0.25db |
| Return loss | ≥55db | ≥65db | ≥30db |
| Durability | ≤ 0.2db typical change, 1000 times mating |
| Operating Temperature | -45 to +85 degree |
| Ferrule Hole Sizes | 125.0+1/-0um, Concertricity: ≤1.0um | 125.0+1/-0um, Concertricity: ≤0.5um | 125.0um, Concertricity: ≤3.0um |
| 125.3+1/-0um, Concertricity: ≤1.0um | 125.3+1/-0um, Concertricity: ≤0.5um | 127.0um, Concertricity: ≤3.0um |
| 125.5+1/-0um, Concertricity: ≤1.0um | 125.5+1/-0um, Concertricity: ≤0.5um | 128.0um, Concertricity: ≤3.0um |
| 126.0+1/-0um, Concertricity: ≤1.0um | 126.0+1/-0um, Concertricity: ≤0.5um | |
Thanks for refer our products, should any question please feel free to contact me.
Takfly looking forward to hearing from you!!
