SD-Zw900 Digital Tempeature and Humidty Controller for Egg Incubator
| Price: |
US $ 50.77/Piece |
| Min Order: |
10/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
SD-ZW900 |
| Temperature Control Range: |
0-99.9degrees Celsius |
| Working Power: |
AC220V+/-15% |
| Installing Size: |
67.5X67.5mm |
| Humidity Control Range: |
0-99%Rh |
Product Description
Factory direct supply, all goods can be customized,
OEM/ODM is available.
Overview
This meter is heart controlled by advanced MCU, using imported high-performance temperature and humidity sensor, can measure and control temperature and humidity signal at the same time, and achieve liquid crystal digital display, also can set up and display separately upper or down limit by the key, so that the meter can automatically fire electrical fan or heat booster to automatically adjust the actual temperature and humidity of the measured environment according to the actual situation. The action indication is outputted by Two normally open contact, genuinely making the meter to achieve intelligence to more adjust to the complex actual situation, so as to achieve the goal of protecting the instruments effectively. This meter is compliant to high and low switchboard, terminal box, Box type substation and so on.
Technical Parameter
1. Power Supply: AC220V±10%
2.Work environment:temperature-20~+50ºC opposite humidity≤95%RH
3.Control range:0~99.9ºC,0~99%RH
4.Control precision:temperature±0.5ºC,humidity±5%RH
5 .Power dissipation: ≤5W
6.Output contact spot:(1)AC220V,3A(resistance load)(2)AC220V,3A(resistance load) Main function and characteristic of the system
1.Two row big screens a surname LED digital display, temperature is four digital integration, humidity is three digital integration.
2.temperature measure and control, measuring range:0~99.9ºC
3.humidity measure and control, measuring range:0~99%RH
4.Can use keys to set up temperature and humidity limit and logic controller figure, and achieve keeping parameter when the electricity is turned off. Installation and connect line
1.The installation of controller - panel style Open pore size:67.5mm×67.5mm External size:72mm×72mm×117mm 2. The installation of sensor.Prepare 35mm lead rail way, also can fix it to the right position tightly using screw.
3.Connect wire picture
