Sdfii- Servo Motor Single Phase LCD Display AC Automatic Voltage Regulator/Stabilizer/AVR

Name: Sdfii- Servo Motor Single Phase LCD Display AC Automatic Voltage Regulator/Stabilizer/AVR
Brand: all-electronics-online.com
SKU: 804981455
Availability: InStock
Rating: 5 (22 reviews)

Price:	US $ 15-20/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Efficiency:	98%
Degree Of Protection:	IP20
Input Voltage:	AC 140-260V
Current Type:	AC
Phase:	Single Phase
Usage:	DBW
Frequency:	Low Frequency
Brand:	Ann

Product Description

Introduction:
SDFII series second generation relay type intelligent LCD display full automatic AC voltage regulator is a brand-new concept product. It is on the basis of years of producing relay type full automatic ac voltage regulator, after improvement, innovation and perfection of design with low energy consumption, over voltage and over current protection,short circuit protection etc. And sets many new technologies such as selective delay, impact resistant, multi function LCD display, energy saving and environmental protection

Advantage:

•Suitable for wall mounting

•Stepless voltage regulation over a wide range

•The high output voltage accuracy (1.5%)
•Surge protection

•Protection against short circuit and overheating
•Differentiation and fault indication
•Informative LCD-display
•Modern design
•urge protection up to 300 V
•Microprocessor control
•High speed regulation
•The wide input voltage range
•The multistage defense

Product Parameter :

Model	SDFII-4000-L	SDFII-6000-L	SDFII-10000-L	SDFII-12000-L
Power capacity	3000W	5000W	8000W	10000W
Input voltage	AC 140-260V
Output voltage	220V±1.5%
Phase	Single Phase
Frequency	50-60Hz
Rated current	15A	25A	40A	50A
Type of stabilization	Electromechanical
Display	LCD digital display
Protection over voltage	250±2V
Protection lack voltage	185±2V
Mode Bypass	Yes
Efficiency	98%
Type of connection	Terminal block
Degree of protection	IP20
Delay	8 second
Temperature protection	110°C±10°C
Ambient Temperature	-10~+45°C
Relative humidity	80%
Waveform distortion	No additional wave form distortion
Dimension of device(LWH)(mm)	430315275	430315275	515350280	515350280
Weight of device	12.5Kg	18Kg	28Kg	30Kg
