| Prod Model: |
WST-70AB |
| Markets: |
North America,South America,Eastern Europe,Africa,Oceania,Western Europe |
| Brand: |
Winston |
| Protective Connection: |
T70u |
| Frequency: |
50Hz/60Hz |
| Max. Working Temperature: |
80degree |
| Protection Grade: |
IP68CS,IP68 |
| Working Pressure: |
Max.1bar |
| Rated Voltage: |
250V (380V) |
| Rated Current: |
16A(8A) |
| Other: |
Very Durable |
| Type: |
Microwave Sensor Switch |
| Standard: |
Standard |
| Certification: |
CE |
| Principle: |
Electric Control |
| Application: |
in Drinking Water |
Product Description
Introduction:
CABLE SUSPENDED FLOAT OPERATED LEVEL SWITCH
It is a simple,user friendly and reliable switch for liquid level detection.By selecting an appropriate
float and cable length,it can be used for small or long range detection of liquids,with or without
impurities,sanitary applications like drinking water and also for explosive liquid or liquid in hazardous
areas.Besides,by using a number of cable floats with appropriate fixation points,it can be used for
multipoint detection.
CONSTRUCTION&OPERATION
It consist of a float,integral with a 3 core electric cable.A fixed micro switch and a moving steel ball
are enclosed within the float casing.A change in liquid level causes the float to tilt up or down around
a pivot,provided in the form of an adjustable stopper or support pipe,at an angle and in the process,
actuating a steel ball to move and operate a micro switch plunger to close or open an electrical circuit
with potential free contacts,to operate auxiliary electrical devices like alarm,pump and solenoid valve.
APPLICATION
Used in sumps,Sewage,factory drainage,sludgy & soil water containing suspensions for automatic
switching of pumps,submerged pumps,solenoid valves,alarms etc.
Specification:
| Float Regulator | Liquid Controller /float switch |
| Rated voltage | 250V(380V)/120V |
| Rated Frequency | 50Hz/60Hz |
| Rated current | 16A(8A)/10A(8A)/10A(4A) |
| Working temperature | 0 degee to 80 degree |
| Mechanical endurance | ≥100.000 times |
| Electric endurance | ≥ 50.000 times |
| Protection grade | IP68CS |
| Standard cable length | 2m 3m 5m 10m 20m as customs required |
| Switch currency | +++ ≥50 000switch workings tested by VDE specialisation |
| Protective connection | T 70U |
| Protection | Waterproof |
| Working pressure | Max.1bar |
| Circuit breaking capacity | Directly KW with 250V |
| Float | Polypropylene |
| Cable | Polypropylene Jacket |
| Counter Weight | Polypropylene Sealed Housing |
| Cable Material | HO7RN- F3x0.75mm2 , PVC (3x0. 5mm2,3x0.75mm2, 3x1.0mm2)
|
