| Prod Model: |
GS-TFL-6K |
| Rated Laser Output Power: |
4000W |
| Laser Wavelength: |
900-1070nm |
| Power Instability: : |
Less Than 2%; |
| Working Method: |
Continuous |
| Max. Power Consumption: |
15kw |
Product Description
Semiconductor laser cladding machine heat treatment for sale
Introduction and technical parameter of equipment
Working table
Three five-axis linkage CNC laser machine:
Using cantilever flying light path movement form, light path are X, Y, Z three-axis linear motion
function, can drive the semiconductor laser source to do three-dimensional exercise. There is a
horizontal axis of the C axis on working table, can drive the workpiece to rotate. For the
convenience of different length of specification of workpiece clamping, tailstock thimble adopts
servo motor drive to move along the workpiece axis. X, Y and Z axis and the horizontal axis C
axis, the tailstock thimble lateral movement X1 axis, five axis totally. The X, Y, Z, and C axis
constitute any triaxial linkage machining system.
Germany 3000W optical fiber coupled diode laser source
| Rated output power | 3000 W |
| The output wavelength | 900-1070 nm |
| Power non-stability rate | + / - 2% |
| Size | 950 x770x1700mm (LxWxH) |
| Weight | 600 kg |
| Working style | Continuous work |
| Laser power supply requirements | three phase 380-480 vac, 50/60 hz |
| Maximum power consumption | 15 KW |
| Working temperature | 10-45 ºC, 5-65 ºC for storage temperature |
| Humidity | 85% maximum @ 35 ºC without condensation |
| Laser safety levels | level I |
| Interface | Profibus DP,Ethernet,RS232 |
| Warranty period | 5 years warranty for semiconductor laser source, other components 2 years warranty |
Mechanical specifications
| Largest diameter | About 70mm |
| Optical lens specifications | 2 inches |
| Weight of standard optical element | About 5 kg (not including nozzle) |
| Optical specification | |
| Beam quality | 110mm.mrad |
| Collimating focal length | 81mm |
| The focal length | 400mm |
| Spot diameter | Ф4.9mm |
| Operating conditions | |
| environment temperature | 10-40ºC |
| Working temperature | Max50ºC |
| The temperature | No condensation |
| Effective water cooling | 500W or above laser source continuous working is recommended |
Installation conditions:
1) installation area: around 100 square meters, height is not less than 6 meters, convenient for operation
2) ambient temperature: 5 ºC to 40 ºC
3) environmental relative humidity: 5% ~ 85%
4) power supply parameters: the three phase four wire system to 380 v + 5%, 50 hz + 1 hz
5) the total power: 40 kva
6) air compressor: Z - 0.53/10 type (displacement 0.53 M3 / Min, pressure is 1.0 MPa).
Dedusting system
Fully closed structure design, smoke caused during processing, if not clean timely, machine
malfunction happened, especially hurt for optical component also will be caused.
This solution with design of dedusting system in the top of machine, matched with huge flow rate
fan, which can make sure smoke blow away timely, ensure machine working smoothly.
