Sf6 Gas-Insulated Voltage Transformer Vt
| Price: |
US $ 100-4000/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
Jdqxf Series |
| Application: |
Instrument |
| Phase: |
Single |
| Coil: |
Core-type Transformer |
| Cooling Method: |
Dry-type Transformer |
| Winding Type: |
Separated Winding Transformer |
| Usage: |
Instrument Transformer |
| Brand: |
Ville |
Product Description
Transformer cabinet is at the bottom of product, main body is in it, there is a silicon rubber composite insulation bushing or high strength porcelain bushing at the middle and primary terminals are at top both sides of product.
A SF6 gas density controller is equipped on the transformer cabinet; it can monitor the SF6 gas pressure in-line. There is a pressure-relief device on the top; the rupture (relief) pressure is 0.7 MPa without oil or explosion risk, and it is free-maintenance.
Main body is inside the cabinet, use the composite insulation of polyester film and SF6 as interlayer insulation, so it has high strength insulation. Coil uses single-staged tower structure, so it has a good shock resistant performance.
Product shell is carried out hot galvanizing or uses cast aluminum alloy, all components including stainless steel fasteners and nameplate etc work in outdoor for long time without rust.
Primary terminal block uses cast aluminum part, the static test load it can bear is no less than 3000N.
Secondary outlet box is a complete structure by casting the aluminum alloy; its sealing structure meets the requirement of IP55, which is dust proof, water proof and air permeable; secondary terminal for wiring uses Phoenix special terminal; it is more conve-Introduction to Structure Symbol Explanation Antipollution Class W2 or W3 Rated Voltage Grade Measurement Coil and Protection Coil Being Separate With Residual Voltage Coil Gas-insulation Single Phase Voltage Transformer nient for operations such as plug-in, pull-out and wiring etc. Optimal Electrode shielded structure improves internal and external field distribution of the product. It has an excellent insulation property. Partial discharge test is carried out under power frequency test voltage.
Seal ring is made of imported fluorocarbon silicone rubber, it is suitable for using in the area where there is great
temperature change or the environmental temperature is extreme. The leakage rate per year is less than 0.5%.
High voltage coil is made of imported polyester film and conducting wires with high insulation strength and stable performance; use imported automatic winding equipment to complete the wire winding and the wrapping of interlayer insulation automatically according to entered instructions.
It can be designed and made with three coils (one primary coil, one secondary coil and one residual voltage coil) or four coils (one primary coil, two secondary coils and one residual voltage coil) according to the requirement of customer.
Integrated design is reasonable; it shows capacitive character under certain voltage
Ningbo Ville Electric Co., Ltd. One of wholly owned subsidiaries of VILLE INDUSTRY, It was invested by VILLE INDUSTRY, It is a well-know listed company in China specialized in R&D of electric power technology, equipment manufacturing and engineering services specialized in research, development, production of transformer and high voltage & low voltage electrical power equipment
Our Transmission and distribution companies can provide with whole solution for transformer substation and switch substation trunkey project!
The rated voltage from 11kV up to 132kV.
It locates in Hi-technical enterprise R & D center zone of Ningbo, Zhejiang province, which is one of the well-know coastal city in China. Its professional engaged in power substation, power plant project and electrical power complete equipments.
Working field: Manufacturing, engineering, designing, executing and commissioning for HV and LV electrical products. Turnkey substation from 11KV to 132KV.
Our transformer factory main working is visiting end user's site do measure and reseach before designe, and providing economic transformer solution for customer. Engineering, manufacturing, executing, commissioning and repairing for different kind of transformer (04kv -500kv ).
The products are mainly used in Steel plant; Power - Fossil fuel plant, Nuclear power plant, Railway, Subway and Airport. Wind power generation; Hydroelectric plant engineering; International power generation plant; Power substation transmission and distribution; Residential housing estate power distribution system and so on.
Transformer factory Product includes:
Three phase double (three)- winding power transformer, generator power transformer, auto power transformer, rectifier transformer for each industry, furnace transformer, movable transformer, traction transformer and reactor, power plant auxiliary and standby transformers, transformers for substations of backbone and distribution networks. Transformer for metallurgical companies etc.
In order to achieve the enterprise's strategic target---being stronger, larger, and superior, we continue to expand throughout the world's markets for power transmission and distribution area. And we also actively attach our team to competition, walking forward to the mission of "First-class worldwide transformer supplier"
Supply the guide drawings and installation manuals information directions on the method of handling, storage, mounting and erection of transformers.
Power equipment application:
Power-fossil fuel plant, Steel plant, Infrastructure- railway, international generation, substation, hydropower station, wind power substation, transmission and distribution.
We has excellent experience and good capacity in complete projects equipments in Generation, Substation, Transmission and Distribution from 400V-330kv, especially in Power plant, Substation construction and Transmission line, including of design, complete equipment, installation, Commissioningand after-sales service, and also design the complete Electrical Solutions according to customer's demand. We are mainly services to International State Power Board, Power Construction Contractor, Power Project Contractor, Factories and the Electric Power Project in the world.
In order to achieve the enterprise's strategic target---being stronger, larger, and superior, we continue to expand throughout the world's markets for power transmission and distribution area. And we also actively attach our team to competition, walking forward to the mission of "First-class worldwide electrical equipment supplier
