Silicon Rubber 12.5kn 52kv Pin Post Insulator

Name: Silicon Rubber 12.5kn 52kv Pin Post Insulator
Brand: all-electronics-online.com
SKU: 620962322
Availability: InStock
Rating: 4.3 (46 reviews)

Price:	US $ 1-10/Piece
Trade Terms:	FOB
Min Order:	100/Piece
Pay Type:	L/C,T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	JMA
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Composite Insulator:	Insulator
Pin Insulators:	Insulator for Export
Application:	High-voltage
Material:	Silicon Rubber

Product Description

The main technique parameter of Pin Insulator :
1.       all tests are in accordance with IEC61109
2.       maximum RIV is 100µV when tested at 1MHz and10% over nominal line ground voltage for indicated system voltage
3.       all units for 220kv 230kv system voltage should be assembled one corona ring at the line end
4.       all units for 345kv or greater system voltage should be assembled with two corona rings, one at each end.
Feature of pin insulator :
1. Excellent electric corrosion-proof property.
2. High mechanical intension.
3. Light weight and easy installation

Basic Data

Model Type	Rated Voltage	Rated Mechinical Load(KV)	Structure Height H. (mm)	Insulating Distance Li. (mm)	Min Creepage Distance(mm)	Lighting Impulse Withstand Voltage(KV)	P.F Wet Withstand Voltage (KV)
FPQ-10/4	10	4	215	125	280	75	42
FPQ-10/5	10	5	250	165	420	105	42
FPQ-24/6	24	6	305	255	715	150	75
FPQ-36/8	36	8	440	320	1000	185	95
FPQ-52/12	52	12	480	415	1225	220	110

Service
Choose our products! You'll get
1) Good quality guarantee (2 years)
2) Factory direct prices
3) On time delivery
4) Free sample
5) Professional technology support

Strict quality controls have been taken to ensure that you'll get reliable products.
a. Material checks before production .
b. Random inspection during production .
c. Inspection before the shipment.

Our products fully comply with well recognized standards such as IEC, BS, ANSI.

FAQ:
1. Q: Do you have a catalog? Can you send me the catalog to have a check of all your products?
A: Yes, We have product catalog. Please contact us, we'll send our catalog by E-mail.

2 Q: I can't find the product on your catalog, can you make this product for me?
A: Our catalog shows most of our products but not all. If you couldn't find it, let us know the specification of your requirements, it usually takes 20-30 days for us to design and make new moulds which match your requirements.

3 Q: What's your payment term?
A: The price FOB Ningbo under payment term is 50% T/T in advance and the balance before shipment.

Chongqing Ziyong Technology Co., Ltd(Wenzhou(Yueqing) Ziyong Electrical Co., Ltd )is a professional supplier and exporter of electric cable connectors and fittings. Our products include a wide range of Aerial Electrical Fittings (Main products like: Insulation piercing connectors, suspension clamps, anchor clamp, etc. ); A variety of Electric Power Fittings (PG clamps, Aluminium alloy stain clamps, wedge clamps, earth rod); Various kinds of terminals, lugs and link fittings; And many other products for power line system.

Our products are widely used in LV & MV power line system. All of our products with highest quality. We are CE certified, have the ISO9001: 2000 certificate, all the produce is according to International Standard, such as NFC, GB and so on. We also offer OEM service of customized requests. We owns the most advanced technology. Have the ability to research and design electricala apparatus by ourselves.

We also hope that we can receive the feedback from you on evaluating our products, offering your good ideas. Let us build up international quality in China together!
