Single Phase 1kVA 2kVA Power Inverter with Ce, RoHS Certificates

Single Phase 1kVA 2kVA Power Inverter with Ce, RoHS Certificates
Price: US $ 1-50/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 5/Piece
Pay Type: L/C,T/T,Western Union,Money Gram
Prod Model: Rainbow Star Series
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Auto Reboot Function: Yes
Color: Green
Max Efficiency: >96%
Phase: Single
Power Source: Electric Power
Application: Electric Tools
Brand: Upsen

Product Description

Single Phase 1kva 2kva Power Inverter with CE, RoHS Certificates
Hybrid Pure Sine Wave Inverter Controller Rainbow Star Series 1000Va-5000Va   (1ph in/1ph out)
Key Features
1:Small size,light weight and potable
2:Compatible to mains voltage or generator power
3:Selectable charging current based on applications
4:Automatically transfer between battery and line modes
5:Smart battery charger design for optimized battery performance
6:Delay before transfer, extra protections for loads under generator mode
7:Selectable input voltage range for home appliances and personal computers
8:Easy to check with inverter condition with LED indication that can be upgraded to LCD
9:output port offer one more choise for user. It can charge for some digital equipments as you want
10:Pure sine wave output.Built-in  transfer switch automatically transfers between inverter power and incoming AC power


Applications
Supply the reliable long back up time power for the home appliances and Portable lights,Electronic Cash Registers,Alarm Systems,Cable Television etc

Technical Specification
ModelRS1000 RS2000 RS3000 RS4000 RS5000
RATED POWER1000VA/800W2000VA/1600W3000VA/2400W4000VA/3200W5000VA/4000W
INPUT
Voltage208/220/230/240 VAC
Selectable Voltage Range
170-280 VAC (For Personal Computers) ; 90-280 VAC
 (For Home Appliances)

Frequency Range
50 Hz/60 Hz (Auto sensing)
OUTPUT

AC Voltage Regulation
(Batt. Mode)

230 VAC ± 5%
Surge Power2000VA4000VA6000VA8000VA10000VA
Efficiency (Peak)90~93%93%
Transfer Time10 ms (For Personal Computers) ; 20 ms (For Home Appliances)
WaveformPure sine wave
BATTERY & AC Charger
Battery Voltage24VDC48 VDC
Floating Charge Voltage27VDC54 VDC
Overcharge Protection30VDC60 VDC
Maximum AC Charge Current20A25 A
SOLAR CHARGER

Maximum PV Array Open
Circuit Voltage

60VDC/150Vdc (Optional)
110VDC/150Vdc (Optional)

Mppt Range @
Operating Voltage

25-60Vdc/25-150Vdc (Optional)

60-110Vdc/60-150Vdc
(Optional)

Maximum Solae Charge Current
40/60A60A
Max Efficiency  >96%
Standby Power Consumption2W
PHYSICAL
Dimension, D x W x H (mm)350 x 130 x 340380 x 130 x 465
Net Weight (kgs)7.47.6812.513.5
