Product Description
Immersion Gold Board PCB for LED Lighting
Material: Aluminum Based
Brand: Polytronics Ventec TOTKING Boyu Bergquist
Thickness: 0.2-5.0 mm
Copper: 1oz-5oz
Thermal conductivity: 1-8 W
Solder resist: TAIYO ink
Max PCB size: 600mm*1200mm
Surface treatment: HASL,immersion gold,OSP
Minimum Hole Size: 0.2mm (+/-0.1mm)
Certification: UL, ISO14001, ISO9001, SGS, TS16949
Used for high power led, electronics, machinery, industrial lighting and so on.
Good price and best price.
| Factory Manufacture Capability |
| NO | ITEM | Techinical capabilities |
| 1 | Materials | FR-4, CEM-3, Al Base, Cooper Base. |
| 2 | Material Type | TOTKING T111, EASTPOWER EPA-M0 |
| 3 | Layers | 1 Layer |
| 4 | Min. core material | PP |
| 5 | Max. board size | 600mm *1200mm |
| 6 | Copper Thickness | 1-4 OZ |
| 7 | Min. board thickness | 0.5 mm |
| 8 | Max. board thickness | 5.0 mm |
| 9 | Min. line width/space | 0.1mm |
| 10 | Min. Letter line width | 0.15mm |
| 11 | Min. Letter height | 0.8mm |
| 12 | Min. hole size | 0.75mm(NPTH) |
| 13 | Hole dia. tolerance | ±0.05mm |
| 14 | solder Mask | White, Black, Green |
| 15 | Outline Tolerance | ±0.15mm |
| 16 | Modeling | Punching, Routing, V-cutting |
| 17 | Special Hole | Blind hole, Blind slot, T-hole, T-slot, Counter sink hole, Cup hole |
| 18 | Peel Strength | >=1.3N/mm |
| 19 | Thermal Stress | 288ºC, 2min |
| 20 | Thermal Conductivity | >=2.0 W/m-k |
| 21 | Thermal Resistance | ≤0.55 ºC/W |
| 22 | Test Voltage | 5 V |
| 23 | Surface Finish | HAL , OSP , Immersion Gold |
| 24 | File Format | Gerber , DPF, HPGL,CAM,DXP,CADM,PADS |
| 25 | Dielectric Breakdown | >=2.5 KV |
| 26 | Max. Package Size | 1200mm*600 mm |
How to get a quote?( need provide us these information as below:)
| Project | | Surface Finish | |
| Note | | Stencil Manufacturing | |
| Number of Layers | | Stencil Material | |
| Material | | Stencil Thickness(um) | |
| Material Thickness(mm) | | Stencil Format | |
| Copper Thickness(um) | | PCB Dimensions(mm) | |
| Solder Mask Color | | Min Finished Hole Size(mm) | |
| Silk Screen Color | | Min Clearance(mm) | |
| Milling | | Min Track Width(mm) | |
Remarks: please send gerber file with these formats: .PCB / .P-CAD / .DXP / .CAD / .Gerber
a) Base material: FR4/ AL/ FPC/ CEM-1/ CEM-3/ 94v0/ Rogers
b) Board thickness: 1.6mm-3.2mm/ 0.3mm-1.2mm
c) Copper thickness: Hoz/ 1oz/ 2oz/ 3oz/ 4oz, ect
d) Surface treatment: eg. Immersion gold/ OSP
e) color of solder mask and silkscreen: Green/White/Black/Red/Blue/Yellow
f) Quantity and board size
Delivery Timescales
Sample
*Single layer 4days
*Double Side 4-6days
*Aluminum PCB 7-10days
* Urgent Routing sample could be pushed 2-3 days earlier with premium.
Mass Production
*Single layer standard 10 days
*Double Side standard 12days
*Aluminum PCB standard 15days
*Material availability dependant.
Package & Shipping Method:
1. Vacuum package with silica gel, Carton box with packing belt.
2. By DHL, UPS, FedEx, TNT
3. By EMS (Usually for Russia Clients)
4. By sea for mass quantity according to customer's requirement
Payment method
1. T/T
2. Paypal
3. Western Union
Primary Competitive Advantages:
Country of Origin
Green Product
Price
Product Performance
Quality Approvals
Service
Small Orders Accepted
Aluminum PCB 6061 Aluminum Single Sided MCPCB 1W/MK HASL Lead Free Applied In Led Panel Light
Commodity IntroductionThis is a type of Aluminum 6061 PCB for the application of Led Panel Light. It's a single sided layer board at 1.6mm thick. The base laminate is from ITEQ, Solder mask and silkscreen from Taiyo. It's fabricated per
IPC 6012 Class 2 using supplied Gerber data. Each 10 boards or panels are packed separately.
Found PCB, established in 2005, Shenzhen Found Printed Circuit Board Co., Ltd. is part of Found group. Found PCB dedicated to provide one-stop service, to meet highest technology, quality and quick turn over challenges with lowest cost.
Shenzhen Found Circuit Board Co., Ltd supply all kinds of PCBs more than 10 years. Products including Rigid PCB (1-20 layers), flex PCB(1-4 layer), metal core PCB, Rigid-Flex PCB, especially in the metal core PCB, they use widly in the LED lighting.
A lot of comepays from Europe and North American buy from Found, cause we are the source, we can offer very good price, we think we can save a lot of your purchasing cost.
We also offer PCB solution. Such as Rigid-flex PCB, a lot of factories in China can not made this kind of the rigid-flex PCB. But Found is good at this...
With several year's rapid development, the production capability of our factory reachs 25, 000 square meters with over 500 employees and 180, 000 sq. M production area. Found PCB has been certified by International Quality System IS09001, ISO14001, TS16949 and UL (E361831).
