Prod Model:	FD-03
Type:	Rigid Circuit Board
Dielectric:	FR-4
Material:	Aluminum Covered Copper Foil Layer
Flame Retardant Properties:	V0

Product Description

Development Status Of PCB Fabrication Technology

Almost all electronic products need to use the circuit board, the circuit board is fixed, the connection, the electronic components of insulation, flame-retardant board. Make the connection of components faster and neater. Easy mass production and maintenance, increase the reliability of electrical appliances. is one of the components of electronic appliances. The circuit board makes the circuit miniature and intuitive, which plays an important role in the mass production and optimization of the fixed circuit.
The research on the automatic testing system of printed circuit board in China began in the middle of the early 90.
At present, the research institutes engaged in this field are comparatively few, and because of the influence of various factors, the research on the automatic optical inspection system of PCB defects also stays at a relatively early level. Because of the foreign printed circuit board automatic testing system price is too expensive, and the domestic has not developed a real sense of the printed circuit board automatic testing equipment, so most of the domestic circuit board manufacturers or using a magnifying glass or projector to check the side of the method.
Because the labor intensity is large, the eye is easy to produce fatigue, the leakage rate is very high.
And with the electronic products towards miniaturization, digital development, printed circuit board also toward high-density, high-precision development, the use of manual testing methods, basically can not be achieved. For higher density and precision circuit boards (0.12~0.10mm), it is completely impossible to test. Detection means of backwardness, leading to the current domestic multilayer board (8-12-layer) of the product pass rate is only $number.

Technical capability & support

Sunthone aims to be the leading PCB manufacturer, and provide quality PCB products for electronic industry.

Layers	1-16 layers	Min Board Thickness(2-layer)	0.2mm
Max Board Size	635 × 1100mm	Min Board Thickness(4-layer)	0.6mm
Min Board Size	20 × 30mm	Min Inner-layer Thickness	0.1mm
Min Trace	0.1mm	Min Annular Ring	0.1mm
Min Space	0.1mm	Min Hole Location Tolerance	±0.075mm
Min Hole Size	0.2mm	Min Hole Size Tolerance	±0.05mm
Board Wrap	≤ 1°	Min Outer Dimension Tolerance	±0.1mm
Solder Mask	Green, Yellow, Red, Black, Blue, White
Surface Finish	HAL, HASL, Immersion Gold, Immersion Silver, Plating Gold, Plating Nickel, Plating Silver, Gold Finger, OSP
Board Material	FR-4, High Tg FR-4, Halogen Free FR-4, Thick Copper FR-4, Aluminium Based, Rogers, Taconic
Acceptable file	Gerber file(RS-274-X or RS-274-D with aperture list and drill files),Protel,PADS,POWERPCB,AutoCAD,ORCAD
CAM software	Genesis, CAM350

Service for productoion

FOUND employs and develops a team of experienced management directors and efficient production workers, with its sustainable development, career planning, advanced training-system and satisfactory welfare for all staff. On the other hand, FOUND strives to improve quality and lead time through management and technology innovation.

Standard leatime

Double sides	4WD
4 layers	5WD
6 layers	6WD
8 layers	7WD
10 layers	8WD
12 layers	8WD
14 layers	9WD
More than 16 layers	Up to difficulty

Competitive Price

FOUND puts many PCB prototype and sample jobs on one panel, and produces them together. And our experienced management team keep the management and production cost under controlled. These advantages provide enough profits to Sunthone, as well as greatly reduce customer's purchase cost.

FOUND works with customers to reduce their purchase cost, by our rich experience in management and manufacture, maximized utilization of materials and facilities, and well-trained operational workers. Sunthone's price can be as low as 20% only of some other competitors on some cases.

Management Innovation	Raw Material Utilization Rate	Facilities Utilization Rate	Labor Efficiency
FOUND	100%	100%	95%
Competitors	50%	30%	50%
Values	Maximized raw material utilization reduces the material cost greatly, and enables Sunthone to use better raw materials.	Maximized facilities utilization improves Sunthone's production efficiency and shorten the lead time.	High labor efficiency reduces labor cost, and enables Sunthone to provide better training and welfare for the workers.
Customer Benefits	Better quality with better raw materials.	Saves valuable time and money for customer.	Well trained and efficient worker improves quality and lead time.

Others service can be provided

Quick response, FOUND will reply Customer's any enquiry within 2 hours;
More than 180 type of PCB can be worked out Every day;
24 hours technique Support;
24 hours Engineering Gerber files treatment.
24 hours English Engineering Questions Confirmation by E-mail.
Experienced Impedance Designer.
Supply the best project fit for production customized

Found PCB, established in 2005, Shenzhen Found Printed Circuit Board Co., Ltd. is part of Found group. Found PCB dedicated to provide one-stop service, to meet highest technology, quality and quick turn over challenges with lowest cost.

Shenzhen Found Circuit Board Co., Ltd supply all kinds of PCBs more than 10 years. Products including Rigid PCB (1-20 layers), flex PCB(1-4 layer), metal core PCB, Rigid-Flex PCB, especially in the metal core PCB, they use widly in the LED lighting.

A lot of comepays from Europe and North American buy from Found, cause we are the source, we can offer very good price, we think we can save a lot of your purchasing cost.

We also offer PCB solution. Such as Rigid-flex PCB, a lot of factories in China can not made this kind of the rigid-flex PCB. But Found is good at this...

With several year's rapid development, the production capability of our factory reachs 25, 000 square meters with over 500 employees and 180, 000 sq. M production area. Found PCB has been certified by International Quality System IS09001, ISO14001, TS16949 and UL (E361831).

We welcome the every opportunity to working for you. We have the good name in the PCB market.
