| Prod Model: |
e2000, LC, SC, ST, MPO |
| IEC 61754-7 Compliant: |
Compact Design, up to 24 Fiber Ribbon |
| Cable Jacket Color: |
Blue,Green,Aqua,Red,Magenta,Beige |
| Adapter Type: |
Sc |
| Channel: |
2 RO 24 |
| Housing Color: |
Aqua,Green, Beige,Yellow, Magenta |
| Boot Color: |
Black |
| Boot Type: |
Round, Flat |
| Polishing: |
APC, PC |
| Cable Jacket Material: |
PVC, LSZH, Ofnr, Ofnp, PE |
| Application: |
Communication |
| Certification: |
ISO9001 |
| Type: |
2 to 24 Cores |
| Connection Structure: |
MPO,LC,FC,St,Sc,MPO |
| Material Shape: |
Ribbon Cable, Mini Round Cable |
| Brand: |
ODM |
| Sheath Material: |
PVC.LSZH |
Product Description
With 15 years history, KOC is a well-established brand popularly accepted in the world-wide market, especially in European and American countries. We are a professional manufacturer of most passive parts such as patch-cord, connector, adapter, attenuator,splitter, WDM serious. For more detail, please check on our website www.koc.com.cn.
In case of need, please do not hesitate in contacting us.
SC 12 fiber fanout fiber optic patch cords
Patch Cord Production Conventional Process Flow Diagram:
Order Confirmation →Cleaving Cable →Passing Through Components And Parts →Striping Cable And Striping Fiber →Epoxy Defoaming →Checking Fiber And Cleaning →Polishing →Inserting Fiber And Curing →End Face Initial Inspection →Optical Indexes Testing →End Face Inspection →Assembling and Crimping →Machine Grinding →Cleaving Fiber And Manual Grinding → NG →Tensile Test →Analysis →Analysis →Appearance Inspection →Packing
Features
1.Low insertion loss and high retum loss
2.Mechanicl properties conform to EN 50173 and EIA-568-A standards
3.For the connector,ceramic ferrule can provide APC type(conical type or step tye) and PC type.
4.All materials meet the RoHS standard.
5.The patch cable can be customized according to customers specific requirements
6.Compliant with Telcordia GR-326-CORE,IEC and ROHS standards
7.Strict quality testing:IL and RL 100% test.
8.A variety of BOOT color choices.
Applications
1.Wiring of local area network between different enterprise buildings
2.Connection of optical links in optical active devices
3.Wiring in communication base station and distrinbtion case
4.Production and testing of optical devices
5.Optical fiber communication system,CATV and telecommunication network
6.LANs and WANs
7.FTTx
Specifications
Fiber mode: Single mode
Test wavelength: 1310nm&1550nm;
Insertion Loss: typical≤0.20dB,Max≤0.30dB;
Return Loss:UPC≥50.0dB; APC≥60.0dB
Repeatability:≤0.10dB
Interchangeability:≤0.20dB
Durability:≤0.20dB,typical change,1000 mating.
Tensile Strength:≥120N(without 0.9mm patchcord) or customized
Applicative cable OD.:∮0.9mm/∮2.0mm/∮3.0mm
Simplex and Duplex are available.
Operating Temperature:-40ºC to +85ºC
Storage Temperature:- 40ºC to +85ºC
SPECIFICATIONS
| Single mode | Multimode |
| Insertion Loss | | |
| Standard Loss ≤ 0.3dB | Standard Loss ≤ 0.3dB |
| Return Loss | ≥ 55dB | ≥ 30dB |
| Durability | <0.2dB typical change,
200 matings | - |
| Operating Temperature | -20 to +70ºC | -20 to +70 ºC |
Note: The price range is for SC-SC Singlemode 12 core breakout 2mm round cable 1m.
