Slrccbl16 RCCB Residual Current Circuit Breaker

Name: Slrccbl16 RCCB Residual Current Circuit Breaker
Brand: all-electronics-online.com
SKU: 737424755
Availability: InStock
Rating: 4.6 (89 reviews)

Price:	US $ 3.6/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	SLRCCBL16
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Arc-extinguishing Medium:	Air
Breaking Capacity:	Low Voltage Circuit Breakers
Certification:	CCC
Operation:	Manual Type
Installation:	Fixed
Speed:	High-Speed Circuit Breaker
Structure:	RCBO
Poles Number:	2,4

Product Description

Construction and Feature
Provides protecting against earth fault/leakage current, short-circuit, overload, and function of isolation
Contact position indication
Provides protection against indirect contact by human body
Provides complementary protection against direct contact by human body.
Effectively protects electric equiment against insulating failure.
Equipped with switched neutral and phase pole
Provides protection against over-voltage
Provides comprehensive protection to household and commercial systems.

Technical Data
Type: Electronic type
Residual current characteristics: AC
Pole NO.: 1P+N
Tripping curve: B, C, D
Rated short-circuit capacity: 4.5kA
Rated current(A): 6, 10, 16, 20, 25, 32
Rated voltage: 240V AC
Rated frequency: 50/60Hz
Rated residual operating current(mA): 0.03, 0.1, 0.3
Tripping duration: Instantaneous ≤ 0.1s
Electro-mechanical endurance: 4000 cycles
Connection terminal: Pillar terminal with clamp
Terminal Connection Heigth: H1=16mm H2=21mm
Over-voltage tripping: 280± 5%
Connection capacity:
Flexible conductor 10mm2
Rigid conductor 16mm2
Installation:
On symmetrical DIN rail 35mm
Panel mounting
