SMA 905 Fiber Optic Connector

Name: SMA 905 Fiber Optic Connector
Brand: all-electronics-online.com
SKU: 800290185
Availability: InStock
Rating: 4.6 (104 reviews)

Price:	US $ 0.9-1/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	SMA
Simplex And Duplex Sc Connector:	Sm and mm
Diameter:	3.0
Boot Color:	Black
Housing Color:	Metal
Fiber Optic Connector:	Low Loss, High Quality
Transmission Medium:	Multimode
Number Of Cores:	Single-Core
Ferrule Endface:	PC(',UPC)
Structure:	SMA
Connector Type:	SMA
Brand:	Koc

Product Description

Product Description
BRIEF INTRODUCTION
The SMA connector is more and more used in the optical fiber communication system, such as metro, data processing network, medical equipment, aerospace equipment. There are two kinds of materials for the SMA connector ferrule, ceramic and metal. For the metal ferrule, the type of SMA905 and the SMA906 are widely used, and the other types can be customized. The ARK can supply metal ferrule and ceramic ferrule. The connector can be supplied in one-piece connector.
The optical fiber connector is one of the most basic passive components in the optical fiber communication. There are difference ferrule materials (ceramic, plastic, metal), a variety of body and boot color to choose. Through the process of curing and polishing, etc., the connector is combined with various of fiber optic cable and made into different kinds of patchcord (jumper), which have been widely applied to the CATV system, communications system, FTTx system, Local Area Networks, Wide Area Networks, Metro,Test equipment, Active device termination and so on. The ARK has nearly 10 years of experience in producing connectors and all of the products are meet the Telcordia and IEC stander, the material compliance RoHS. If you have other special requirements, the ARK will be specifically for your customization to meet your needs.
SPECIFICATIONS

ITEM	Parameter
	Multi-mode
Ferrule material	Metal OR Ceramic
Insertion Loss	Metal: typical≤0.60dB,Max≤1.00dB	Ceramic: typical≤0.20dB,Max≤0.30dB
Ferrule OD.	∮3.0mm, customized( metal type)
Ferrule material	Metal OR Ceramic
Ferrule Specification	127+3/-0μm, Concentricity: ≤3.0μm
Operating Temperature	-20ºC to +70ºC
Storage Temperature	-40ºC to +85ºC

Shenzhen KOC Communication Co., Ltd. Is specialized in fiber optic communication product manufacture. Our products range from the basic components to end products, including passive and active categories as follows: Basic Components: Connector kits, Adapter kits, Attenuator kits.

Passive products: Connector, Adapter, Attenuator, Patch-cord, ODF and enclosure.

Active products: Media converter, Transmitting and receiving assemblies, such as laser diode assembly, PD and PIN/TIA assembly, sub-assemblies such as TOSA, ROSA, BOSA.

FTTH System: Gpon: OLT, ONU, PLC

Headquarter located in Shenzhen, China, we have branch companies, representatives and distributors in Europe, America, Middle East, South Asia. KOC products are well accepted and sold in these areas.

We provide all our products with high quality, competitive price, short delivery lead time and excellent after-sales services.

About KOC

Located in Shenzhen, China, KamaxOptic Communication Co. Ltd., well-known as KOC, is specialized in fiber optic communication products and accessories. She offers precise customized solutions for various customers involved in telecommunication, broadcast, CATV and network industry worldwide.

Our quality is guaranteed by the scientific management with the assistances of professional personnel, advanced testing equipments and efficient ERP system under the strict guidance of ISO9001: 2000, from supplier evaluation to inbound material examination, from processing monitoring to permanent inspection, from packing to shipping. We do care for every detail!

To be dedicated to be a popular manufacturer with her quality products, satisfactory services and attention to details through the full commitment of each personnel to work as one team in an effort to exceed our customer expectations.

To operate the business in a transparent and honest manner, that our customers, our associates and our business partners are proud to play their part in our success.

Please visit us website for more information: http://www.koc.com.cn
