| Prod Model: |
ETR 011 |
| Markets: |
North America,South America,Eastern Europe,Africa,Oceania,Western Europe |
| Sensor Element: |
Ntc |
| Reaction Time: |
5 Sec. |
| Contact Type: |
Change-Over Contact (Relay) |
| Dimensions: |
64.5 X 42 X 38mm |
| Weight: |
Approx. 70g |
| Fitting Position: |
Vertical |
| Protection Type: |
IP20 |
| Protect Feature: |
Sealed |
| Quality Guarantee: |
2 Years |
| Usage: |
Air Purifier |
| Certification: |
CE |
| Type: |
Temperature Sensor |
| Display Type: |
LED |
| Control Type: |
Electronic |
| Material: |
Plastic |
| Brand: |
Winston |
Product Description
Professional Supplier of Thermostat and heater, all got CE.
Model have: KTO 011, KTS 011, SM010, TL-10B, TL-10A, ZR 011, FTO 011, FTS 011, FTD 011, FZK 011, ET 011, MFR 012, EFR 012. HG 140, HGL 046, CR 030, CR 027, HV 031, CS 028, CSF 060 and so on.
More details, please contact us.
Electronic Thermostat ETR 011
Large setting range
Small hysteresis
Optical operating display (LED)
Change-over contact
Clip fixing
The electronic thermostat is used for controlling heating and cooling equipment, filter fans or signal devices. The thermostat registers the surrounding air and can switch both inductive and resistive loads via relay with change-over contact. The LED integrated in the adjustment knob is lit when the NC contact is closed (e. G. When a connected heater is operating).
Technical Data
| Switch difference | 4K (± 1K tolerance) at 20°C/68°F |
| Sensor element | NTC |
| Reaction time | 5 sec. |
| Contact type | change-over contact (relay) |
| Service life | > 50,000 cycles |
| Max. switching capacity (relay output) | 240VAC, 8 (1.6) A |
| 120VAC, 8 (1.6) A |
| 24VDC, 4A |
| Optical indicator | LED |
| Connection | 5-pole terminal, clamping torque 0.5Nm max.: rigid wire 2.5mm² stranded wire (with wire end ferrule) 1.5mm² |
| Mounting | clip for 35mm DIN rail, EN 60715 |
| Casing | plastic according to UL94 V-0, light grey |
| Dimensions | 64.5 x 42 x 38mm |
| Weight | approx. 70g |
| Fitting position | vertical |
| Operating / Storage temperature | -40 to +85°C (-40 to +185°F) |
| Operating / Storage humidity | max. 90 % RH (non-condensing) |
| Protection type | IP20 |
Art. No. | Operating voltage | Setting range | Approvals |
| 01131.0-00 | 230VAC, 50/60Hz | -20 to 60°C | CE |
| 01131.9-00 | 120VAC, 50/60Hz | -4 to 140°F | CE |
