Small Plastic Float Level Switch (CX-FLM-RF-260S)

Name: Small Plastic Float Level Switch (CX-FLM-RF-260S)
Brand: all-electronics-online.com
SKU: 749930705
Availability: InStock
Rating: 4.9 (100 reviews)

Price:	US $ 15/Piece
Trade Terms:	FOB,CIF,EXW
Min Order:	1/Piece
Pay Type:	T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	CX-FLM-RF-260S
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Install Mode:	Optional
Float Ball Size:	Optional
Temperature:	-20~100c
Switch:	Nc/No
Power Supply:	220V
Accuracy Error:	±2mm (in Water)

Product Description

CX-FLM-RF-20F Small float level switch

Brief introduction
1.This type flow switch has small structure and wide usage and suit for the external environment
2.Bar color is orchid , bar length is 67mm,90mm,100mm, diameter is 28mm ,thickness is 28mm , screw is 15mm ,M10X1

Principle
The sensor install one or more reed switch , then this pipe drill through one or more empty and inbuilt ring magnetic float ,the reed switch will have the relative action and the resistance will change when the float with magnet drift up and down and emit a switch signal

Dimension

Main parameters

Installation	Top or bottom-mounted (vertical +/-20 ºC)
Screw	M10
Electric connection	300mm, UL1430 AWG22
Working pressure	15 Bar
Working temperature	-10~75ºC
Accuracy	+/-2mm
Switch type	N.C./N.O
Working voltage	220VAC
Working current	0.70A
Contact capacity	50w
Working life	1000000times
Float dimension	Dia.28 * dia.8.50*28
