Smaller Lithium Battery 11.1V 31000mAh Lithium Battery Pack

Prod Model:	LP0111-310K-L
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Warranty:	One Year
Battery Type:	18650 Battery
Delivery Date:	15days
Type:	Lithium-Ion Battery Pack
Connection Mode:	Series and Parallel

Product Description

Smaller Lithium Battery 11.1V 31000mAh Lithium Battery Pack with PCM

Quick Detail:
Brand Name: QUAWIN/OEM
Model Number: LP0111-310K-L
Type: Li-ion, Li-ion battery, Lithium battery
Place of Origin: Guangdong China (Mainland)
Nominal Voltage: 11.1V
Nominal Capacity: 31000mAh
Cell: Panasonic 3100mAh Battery
Pack: Blue or black PVC Shrink tube
Size: 58(T) X 200(W) X 70(H)mm
Weight: 1500g
Composed Type: 3S10P
Delivery time: 5-7days
Cycle life: 500 times
Warranty: 12 months
Packing: Antistatic bag /white box and standard export carton/customized

Packaging & Delivery:
. Netural labels, Polybag, PVC, Color box, Customised package
. Netrual packing/Cartoon box with less than 10KGS
. Delivery Detail: Sample within 3 work days, 7~15 days for bulk order

Specifications:
Product Name:11.1V 31000mAh Li-ion battery pack
Product number: LP0111-310K-L
Model No.: 18650R-3S10P (31000mAh)
Voltage:11.1V
Capacity:31000mAh
Maximal charging current:2A(Adjust)
Constant discharge current:1~10A(small current discharge, Adjust)
Peak discharge current:≥ 30A(Adjust)
Life of battery:About 500 times cycle
Charging temperature(º C):0º C~45º C; 32oF~113oF
Discharging temperature(º C):-20º C~60º C; -4oF~149oF
Storage temperature(º C):-20º C~45º C; -4oF~113oF
Dimensions(mm):58(T) X 200(W) X 70(H)mm
(as per customers'requirements)
Weight(Kg)About 1500g
Over charger protection voltage(V):12.6V± 0.05V
Over discharge protection voltage(V):9.0V± 0.25V
Protection Temperature(º C):70º C± 5º C
Warranty:12 month (free)
Requirements:With label, plug, connector, OEM accept.

Specification:
High capacity, high discharge long work, life long, save and environmental protection.
Application:
WiFi device, communication device, medical equipment, instrument, LED lamps, transportation sign, portable family appliance, electronical tools and toys etc.

The Suitable Charger Model No.:QW111-050-L
Charger input:100V~240VAC 50-60Hz
Charging mode:Constant voltage constant current (CC/CV)
Charging voltage:12.6V± 0.2V
Charging current:5.0A± 0.1A
Charging time:6-7 hrs(standard)
Charger working instruction:Be in charging the red light, be full of charging the green light;

Product Advantages:
1). Green product
2). Long standby time
3). One year warranty
4). Excellent safety performance
5). Excellent storage performance and low self-discharge rate
6). Short circuit testing passed
7). Overcharge testing passed
8). Over discharge testing passed
9). 150C thermal shock test passed
10). 1.2m drop testing passed

Spotlight:
1). Provide both single cells and battery packs
2). 100% inspection before delivery
3). Inspects inner resistance, discharge platform and self-discharge
4). Manufacturer of 18650 lithium ion battery, lithium polymer battery etc.
5). Tablished quality control systems under ISO9001
6). Stomized packs, tags, labels, plugs, connectors, over current protection,
Temperature cont8. L protection are available

Shipping terms:
1). Samples checking: Sending by Express ( DHL/UPS/FedEx/TNT, by air)
2). Bulk production: Sending out by cargo shipping / air freight / Express(DHL/UPS/FedEx/TNT), or we can accept other shipping terms according to your requirements.
3). We are not responsible for any accidents, delays or other issues that are caused by the shipping.

Safety Precaution:
1). Do not throw battery into water or make it wet;
2). Keep the battery away from heat source(like fire or heater);
3). Do not throw the battery into fire or heat the battery;
4). Forbid to hammer to trample the battery;
5). Forbid disassembling the battery in anyway

26650/4S2P-12V/6400mAh LiFePO4 Battery Pack
Model:
Item	Specification		Remark
Nominal capacity	6400mAh		0.2C discharge Cell: 26650
Nominal voltage	12V		3.2V / 1Cell
Charging voltage	14.4V±0.05V		3.6V / 1Cell
Charging method	CC/CV		(Constant-current and -Voltage with Limited current
Standard charging time	2000mA/3.5hour , 3500mA/2hour		Battery capacity÷charging current×1.5
charging current	3300mA ( 0.5C )		0 ~ +40 °C
Maximum charging current	6400mA ( 1C )		0 ~ +40 °C
Continuous discharge current	6400mA ( 1C )		-20 ~ +60 °C
Maximum discharge current	6400mA ( 1C )		-20 ~ +60 °C
Discharge cutoff voltage	9.2V		2.3V / 1Cell
Short circuit protection	Exterior short circuit		Automatic recovery
Internal resistance	≤ 200mΩ		AC Impedance 1kHz
Cycle life	≥10 00
Operating temperature	Standard Charge	0 ~ +40 °C
	Standard Discharge	-20 ~ +60 °C
Outline dimension	L106*W54*H72mm		Length x wide x height
Pre-wired			Red = Positive,Black = Negative
Protection Circuit Module:PCM-L04S20-292
Balance voltage
Balance current
Maximal continuous charging current	10A
Maximal continuous Discharging current	10A
Over-charge detection voltage	3.90±0.025V		single cell
Over-charge release voltage	3.80±0.05V		single cell
Over-charge detection delay time	0.5S_1.5S		single cell
Over-discharge detection voltage	2.30V±0.08V		single cell
Over-discharge release Voltage	2.70±0.1V		single cell
Over-discharge detection delay time	50mS_150mS		single cell
Over-current detection	30±10A		can adjust
Over-current delay time	5ms_15ms
