| Prod Model: |
MT09 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Mid East,Eastern Asia,Western Europe |
| Engine Cut: |
by SMS and Online |
| Warranty: |
365days |
| Frequency: |
Quad Band |
| Track By: |
SMS or GPRS |
| Color: |
Black |
| Mini Size: |
40*58*14.5 (Mm) |
| Wight: |
180g |
| Water-Proof: |
Yes |
| GSM Chip: |
U-Blox Chipset |
| Power Consumption: |
Low |
| Type: |
GPS Tracker |
| Use: |
Automotive |
Product Description
Free Online Tracking by website,
Free register car by only one command easily!
Tracking car real address by mobile SMS with city, street name.
1. Track on command or by time interval or by distance.
2. Arm/disarm by SMS or phone call.
3. Check the car's real physical address, such as city name & street name;
4. Track by mobile SMS to get the latitude, longitude, speed, direction & odometer etc.
5. Check the location directly by the Google map's URL;
6. Online website tracking by GPRS data network;
7. Over-speed alert, Geo-fence alert;
8. Cut off engine to stop the car safely by SMS/GPRS(optional);
9. Built-in shock sensor for power saving & triggering alarm
10. Wide working voltage range, from 6V-30VDC, suitable for motorcycle or car.
How to track car location by mobile SMS:
Send command CHK, get car location and status;
Send command MAP, get car location google map's link;
Send command ADD, get car real address directly!
How to control the car by SMS command:
Send STP to stop the car,
Send ARM to arm the system,
Send DSM to disarm system.
Installation Steps:
(1) Please read the manual carefully before installation. Please prepare a valid GSM SIM card with Caller ID Display & GPRS function;
(2) Please use the screw driver to open the cover;
(3) Insert the valid GSM SIM card, then turn on the power switch;
(4) Close the cover, and fix the main unit tightly with the wiring harness at the correct place, please make sure that the side with GPS antenna is placed upside to sky, please make sure to install the main unit at broad place so that it can receive GPS signal well. For motorcycle, it is better to install inside the head bulb light where there is power supply and water proof. For vehicle, it is better to install inside the upper rim of the driving room or inside the dashboard.
(5) Do the wring connection according to the diagram;
(6) Call the SIM card, to check if rings, if not, then check the power supply and the change the place of installation;
(7) If it rings when calling the SIM card, then send SMS to the tracker to check the GPS coordinate, if the GPS location is not correct, then fix the main unit to other place so that it can receive better GPS signal.
(8) IMPORTANT: The side with GPS antenna must be placed upside to the sky and kept away from the metal materials, otherwise, it can't get GPS signal well.
Our TOPTEN models developed bases on car user practical need,
It's very easy to operate and command are all simple to remember and send,
Model Small volume make it easy to hide in car/motorcycle.
| MT09 Packing List |
|
| Main unit | 1pc |
| 4pin wiring | 1pc |
| Manual | 1pc |
