| Prod Model: |
VT200 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| GSM Chip: |
Quectel M35 |
| GPS Chip: |
Ublox GPS Tracker |
| Is Customized: |
Yes |
| Dimension: |
90*53*27mm |
| Input Voltage: |
9 ~ 36 VDC |
| Weight: |
92g |
| Backup Battery: |
650mAh |
| Sos Emergency Call: |
Yes |
| Door Status Detection: |
Yes |
| Crash Alarm: |
Yes |
Product Description
Mini GPS Vehicle Tracker With SOS Button(VT200)
VT200 is a newly developped mini GPS vehicle tracker, a very cost-effective tracking device for all kinds of vehicles, it can be used as a GPS tracker and a car alarm, has tracking, Arm/Disarm by SMS or Call, with ACC on /Door open/Movement alarm to protect your vehicles from pilferage. If equiped with RFID part, the device can realize automatic Arm/Disarm, to protect your vehicle in a easy and confortable way. It is very small in size, easy concealed and installed, a low cost option for VT310N.
Functions & Features
1. Harsh braking and harsh acceleration alarm
2. Check the vehicle's location by SMS or GPRS
3. Set automatic tracking by distance or time interval
4. Cut off engine by SMS gradually for safety
5. Monitor the voice remotely by phone
6. Arm/disarm system by phone call or SMS
7. ACC on alarm, Door open alarm, Movement alarm in Arm status, can be used as an alarm
8. Geo-Fence Alert. If the car oversteps the boundary, it will send out alert
9. Over-speed Alert
10. SOS button, call for help (optional)
11. Mileage report
12. User can check the vehicle's real address name (city, street, etc) by SMS or Website (optional, need platform's support)
13. Small size with backup battery. Anti-tamper design, once power supply is cut off illegally, it will send out alert.
14. Location to SMS with Google map's link
15.2 inputs, 2 outputs and 1 analog input
16. Remote monitor fuel consumption (optional)
17. Remote monitor temperature (optional)
Application
Suit for any vehicle; Upgrade the ordinary car alarm to GPS alarm system; Track the vehicle online
Complete Set:
Standard Package:
Main unit
GSM antenna
GPS antenna
8-pin Wire harness
Relay
Microphone
Optional Accessories
Special USB cable
Active RFID kit
Passive RFID kit
| Technical Specificatioins: |
| Main unit size: | 7.5*5.4*2.5 (CM) |
| Weight of the main unit: | 125g |
| Working temperature: | -20 ~ +75 Celsius degree |
| Humidity: | upto 75% non-condensing |
| GSM frequencies: | Quad-band: 850MHz/900MHz/1800MHz/1900MHz |
| GPS chip: | Latest SiRF-Star III chipset |
| Working voltage: | +6~24 VDC |
| Power Consumption: | Working current: 20~1000mA;
Static current: 20~30mA;
Peak current of sending GSM signal: 1000~1200mA;
Peak current of receiving GSM signal: 600~800mA; |
| Inside Backup battery: | Rechargeable 3.7V 650mAh Li-ion battery |
| Packing Measures: | |
| Neutral | Dimension (mm) | Weight (KG) | Capacity |
| Box | 165x155x50 | 0.45 | 1 set |
| Carton | 470x340x310 | 15 | 30 sets |
